Поз.
Артикул
Описание
27
BANJO UNION HEATING CONNECTION,K 169122
27
BANJO UNION , Replaced By: N915052006005
30
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
30
PLASTIC PIPE RISING PIPE 4X6 MM
33
BUSHING , Replaced By: N915062004000
33
BUSHING , Replaced By: N915062004000
33
SLEEVE LEAK LINE
36
BANJO UNION HOSE WIDTH, / I.D., 4/10 MM
79
SEAL RING18.72X2.62 MM,WABCO,002 0,012 0
80
LOCK RINGTO 001 431 37 05,4 375193
81
SEAL RINGTO 001 431 37 05,4 375193
82
REPAIR KIT VALVE KIT TO 001 431 37 05,4 375193
82
REPAIR KITTO 001 431 48 05,4 375193
82
REPAIR KITTO 001 431 37 05,4 375193
82
REPAIR KITTO 001 431 95 05
82
REPAIR KITTO 001 431 34 05,4 375193
82
BRAKE VALVE SEAL RING TO 001 431 18 05,4 412020
82
REPAIR KIT , Replaced By: A0024306581
82
REPAIR KIT , Replaced By: A0004304606
82
REPAIR KIT , Replaced By: A0024301660
141
FITTING ,4 412020
144
T-FITTING RELAY VALVE,CONNECTION: "20"
147
FITTING ,4 667210
150
T-FITTING
156
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
159
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
162
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
195
VALVE ,4 412020
198
REPAIR KIT ,4 412020
201
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
204
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
207
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
210
SEAL RING FUEL LINE TO FEED PUMP
213
FITTING ,4 412020
222
SEAL RING PNEUMATIC VALVE
222
SEAL RING , Replaced By: N007603010110
225
HOLLOW SCREW LINE CONNECTION
231
BRACKET ,4 412020
234
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
234
NUT , Replaced By: N913004008001
237
SCREW
240
NUT TWO-WAY VALVE TO BRACKET
243
VALVE PARKING BRAKE VALVE GRAU
243
VALVE PARKING BRAKE VALVE GRAU
243
VALVE PARKING BRAKE VALVE WABCO
243
VALVE , TO BE EXHAUSTED UP TO CHASSIS 4 261995, Replaced By: A0004308681
243
VALVE , TO BE EXHAUSTED UP TO CHASSIS 4 230076, Replaced By: A0004308581
243
VALVE PARKING BRAKE VALVE WABCO, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
246
SEAL RING12.42X1.78 MM,WABCO,002 0,012 0
252
VALVE SEATWABCO,002 0,012 0
255
SEAL RING32.99X2.62 MM,WABCO,002 0,012 0
258
SEAL RING6.07X1.78 MM,WABCO,002 0,012 0
261
VALVEWABCO,002 0,012 0
264
SPRINGWABCO,002 0,012 0
267
SEAL RING18.72X2.62 MM,WABCO,002 0,012 0
270
SEAL RING8.13X1.78 MM,WABCO,002 0,012 0
273
SEAL RINGWABCO,002 0,012 0
276
PROTECTIVE CAPWABCO,002 0,012 0
279
HANDLETO 000 430 85 81,WABCO,004 0
280
GASKET KIT PARKING BRAKE VALVE GRAU
282
REPAIR KITTO 000 430 86 81,WABCO
282
REPAIR KITTO 000 430 57 81,43 81,WABCO,0020,0120
282
REPAIR KITTO 000 430 85 81,WABCO,004 0
285
SEAL RING FUEL LINE TO FEED PUMP
288
HOLLOW SCREW , Replaced By: N915036010108
288
HOLLOW SCREW FUEL LINE TO FEED PUMP
999
VALVE HAND BRAKE VALVE WABCO, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
VALVE HAND BRAKE VALVE WABCO, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
SPRINGWABCO,002 0,012 0
999
PLUG FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24", 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
FITTING , Replaced By: A0019972572
999
FITTING CONNECTION "4"
999
BRACKET ,4 412020
999
PLUG TWO-CIRCUIT BRAKE VALVE,CONNECTIONS: "21,22", 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
