Поз.
Артикул
Описание
42
BRACKET , Replaced By: A3874292040
42
BRACKET AT FRAME
42
NUT LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
48
BRACKET , Replaced By: A3874292140
48
BRACKET , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A6204294940
48
BRACKET AT FRAME
48
BRACKET , Replaced By: A3464290840
48
BRACKET , Replaced By: A3874292140
51
RIVET BRACKET TO FRAME
291
BRAKE LINE COUPLING SUPPLY, RED
291
BRAKE LINE COUPLING , Replaced By: A0004297830
291
BRAKE LINE COUPLING SUPPLY, RED
291
BRAKE LINE COUPLING SUPPLY, RED
291
BRAKE LINE COUPLING SUPPLY, RED
294
BRAKE LINE COUPLING BRAKE,YELLOW BOSCH
294
BRAKE LINE COUPLING , Replaced By: A0004297930
294
BRAKE LINE COUPLING BRAKE,YELLOW WESTINGHOUSE
294
BRAKE LINE COUPLING BRAKE,YELLOW KNORR
294
BRAKE LINE COUPLING BRAKE,YELLOW GRAU
294
BRAKE LINE COUPLING , Replaced By: A0004297830
294
BRAKE LINE COUPLING SUPPLY, RED
297
COVERTO 000 429 49 30
297
COVERTO 000 429 49 30
300
SEAL RING , Replaced By: A0004296930
300
BRAKE LINE COUPLINGTO 000 429 38 30
300
SEAL RING"WABCO"
300
SEAL RING , Replaced By: A0004292184
300
SEAL RING"WABCO"
303
SEAL RINGTO 000 429 38 30
306
COVERTO 000 429 51 30,4 434235
309
GROOVED PINTO 000 429 51 30,4 434235
312
SEAL RING"GRAU"
312
SEAL RING"GRAU"
315
COVERTO 000 429 38 30
315
COVER SUPPLY, RED "WABCO"
318
COVER"WABCO", NOT USED
321
REPAIR KITTO 000 429 37 30
321
REPAIR KIT , TO 000 429 49 304 434235
321
REPAIR KITTO 000 429 78 30,4 434236
321
REPAIR KITTO 000 429 63 30
321
REPAIR KITTO 000 429 37 30
324
REPAIR KIT"KNORR"
327
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
330
FITTING BRAKE LINE COUPLING TO BRACKET
333
NUT BRACKET TO SIDE MEMBER
339
BRACKET , Replaced By: A3353170884
339
SHIM BRACKET TO FRAME
342
BRACKET , Replaced By: A6454310740
342
BRACKET FUEL LINE TO BELL HOUSING
345
SCREW BRACKET TO EXHAUST MUFFLER BRACKET
348
SCREW END PIECE TO EXHAUST PIPE M 10X25
351
NUT END PIECE TO EXHAUST PIPE
354
NUT , Replaced By: N910113010000
354
NUT STRAP TO BRACKET
357
T-FITTING EXHAUST BRAKE 3/2-WAY VALVE
360
SEALING CORD COMPRESSED-AIR-LINE PLUG-CONNECTION
363
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940103
363
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
366
NUT LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
999
PLUG TWO-CIRCUIT BRAKE VALVE,CONNECTIONS: "21,22", 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
BRACKET ,4 412020
999
FITTING CONNECTION "4"
999
FITTING , Replaced By: A0019972572
999
PLUG FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24", 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
SPRINGWABCO,002 0,012 0
999
VALVE HAND BRAKE VALVE WABCO, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
VALVE HAND BRAKE VALVE WABCO, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
