Поз.
Артикул
Описание
108
BRACKET AT CROSS MEMBER
111
BRACKET LINE MOUNTING
141
BRACKET FUEL LINE
142
SCREW BRACKET TO BUMPER,LEFT M 10X25
143
NUT BRACKET TO SIDE MEMBER,XB209706
144
SCREW BRACKET TO TRANSMISSION M012X1,5X20
147
LOCK WASHER FITTING TO BRACKET
168
BRAKE HOSE LEFT AND RIGHT FRONT WHEEL BRAKE CYLINDERS
168
BRAKE HOSE , Replaced By: A3844207248
168
BRAKE HOSE FROM QUICK-RELEASE VALVE TO COMBINATION CYLINDER,RIGHT
189
CLAMP HOSE TO FITTING AND TO OIL TANK
189
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
195
WASHER PLUG SOCKET TO BRACKET
204
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
204
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
204
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
204
TEST CONNECTION
207
T-FITTING DIAPHRAGM CYLINDER,CONNECTION: "11",5 272559
207
T-FITTING DIAPHRAGM CYLINDER,CONNECTION "1"
207
T-FITTING RIGHT TRISTOP CYLINDER,CONNECTION: "11",A 069205
218
ADAPTER FITTING LEFT,DIAPHRAGM CYLINDER
219
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
222
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
222
THRUST RING LOCKING VALVE
222
THRUST RING LOCKING VALVE TO TRAILER CONTROL VALVE,CONNECTION: "42"
225
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
999
ADAPTER FITTING DIAPHRAGM CYLINDER,CONNECTION: "12"
999
BRACKET COMPRESSED AIR LINES,11.97
999
BRACKET CROSS MEMBER "4"
