Поз.
Артикул
Описание
1
REAR FENDER LEFT
2
REINFORCEMENT LEFT
3
SIDE MEMBER LEFT
6
END PIECE LEFT
7
PILLAR , 016 UP TO CHASSIS 049099, 018 UP TO CHASSIS 052477, 019 UP TO CHASSIS 052616, Replaced By: A1086300910
10
PILLAR CENTRAL LEFT
11
HINGE TOP LEFT, 012 FROM CHASSIS 000081,014 FROM CHASSIS 000024
12
BUSHING
13
HINGE PIN , Replaced By: A1157330015
13
PIN
14
GREASE NIPPLE
15
HINGE BOTTOM, 012 FROM CHASSIS 000081, 014 FROM CHASSIS 000024, 015 FROM CHASSIS 000015
21
ROOF RAIL INSIDE LEFT
24
ROOF RAIL OUTSIDE LEFT
27
ROOF RAIL LEFT
29
PILLAR OUTSIDE LEFT
30
WHEELHOUSE REAR LEFT
31
WHEELHOUSE REAR OUTSIDE LEFT
32
ROOF RAIL INSIDE LEFT
33
STRUT
34
BOTTOM SPARE WHEEL WELL,LEFT
35
CLAMP ON LEFT SPARE WHEEL WELL PLATE
36
STRUT
37
INSULATING HOSE
38
SIDE MEMBER , Replaced By: A1096300140
999
ROOF RAIL RIGHT
999
SIDE MEMBER , Replaced By: A1096370240
999
ROOF RAIL INSIDE RIGHT
999
ROOF RAIL OUTSIDE RIGHT
999
SUPPORT OUTSIDE RIGHT
999
ROOF RAIL , UP TO CHASSIS 038030, Replaced By: A1096370445, +001A1096300635, +001A1096300835
999
SUPPORT OUTSIDE LEFT
999
ROOF RAIL ,038030, Replaced By: A1096370345, +001A1096300535, +001A1096300735
999
HINGE TOP RIGHT, 012 FROM CHASSIS 000081, 014 FROM CHASSIS 000024, 015 FROM CHASSIS 000015
999
HINGE PIN , Replaced By: A1157330015
999
WHEELHOUSE REAR OUTSIDE RIGHT
999
ROOF RAIL OUTSIDE RIGHT
999
ROOF RAIL INSIDE RIGHT
999
ROOF RAIL RIGHT
999
RECESS SPARE WHEEL WELL,RIGHT
999
END PIECE RIGHT
999
SIDE MEMBER RIGHT
999
REAR FENDER RIGHT
999
ROOF RAIL OUTSIDE LEFT
999
ROOF RAIL , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A1096300735
999
ROOF RAIL LEFT
999
RECESS , Replaced By: A1086300042
999
BUFFER REAR SEAT BENCH BACKREST FRAME MOUNTING, 016 UP TO CHASSIS 043198,018 UP TO CHASSIS 044203,019 UP TO CHASSIS 044488
999
PILLAR RIGHT
999
PILLAR LEFT
999
PILLAR RIGHT
999
PILLAR , 016 UP TO CHASSIS 049099,018 UP TO CHASSIS 052477,019 UP TO CHASSIS 052616, Replaced By: A1086301010
999
WHEELHOUSE REAR RIGHT
999
ROOF RAIL INSIDE RIGHT
999
REINFORCEMENT RIGHT
999
PILLAR OUTSIDE RIGHT
