Поз.
Артикул
Описание
10
REAR LID SHELL
14
HINGE LEFT
20
PLATE
26
FLAP FILLER NECK
32
BRACE , 012 UP TO CHASSIS 073515, 016 UP TO CHASSIS 015906, 018 UP TO CHASSIS 015086, 019 UP TO CHASSIS 015295, Replaced By: A1157580897, +001A1157580997
38
LOCK
42
RUBBER BUFFER , Replaced By: A1239870040
42
RUBBER BUFFER
46
BASE PLATE
50
PLATE
50
PLATE , Replaced By: A1167500011
58
FASTENER LESS KEY
62
KEY , STATE LOCK NUMBER WHEN ORDERING THE LOCK NUMBER MUST NOT BE IDENTICAL WITH THE LOCK NUMBER(MASTER AND SECONDARY DEY SYSTEM)OF THE CAR
66
PAD
70
NUT
74
HANDLE
80
PAD HANDLE TO REAR LID
88
RUBBER BUFFER
92
SPRING LEFT
98
RUBBER BUFFER , Replaced By: A1119871740
106
SPRING
110
SEAL
114
MERCEDES STAR
120
RUBBER RING
999
KEY , Replaced By: A1087600206
999
KEY TO SWITCH BOX, 001313
999
SCREW
999
HINGE RIGHT
999
BRACE , 012 UP TO CHASSIS 073515, 016 UP TO CHASSIS 015906, 018 UP TO CHASSIS 015086, 019 UP TO CHASSIS 015295, Replaced By: A1157580897, +001A1157580997
999
SPRING , Replaced By: A1087580136
999
SPRING RIGHT
999
KEY
999
FASTENER
999
LOCK WITH KEY, WITH LOCK NUMBER UNDEFINED,FOR STORAGE PURPOSES ONLY
999
FLAP , 012 UP TO CHASSIS 041934, 014 UP TO CHASSIS 033457, 015 UP TO CHASSIS 002384, Replaced By: A1117505606
999
SPRING , Replaced By: A1087580336
999
SPRING , Replaced By: A1087580436
999
SHIM , Replaced By: A1087580105
999
RUBBER BUFFER
999
INTERMEDIATE LAYER11 MM, FROM CHASSIS: 010 002636 015 000135 048481
999
INTERMEDIATE LAYER , Replaced By: A1237580397
999
INTERMEDIATE LAYER6 MM, FROM CHASSIS: 010 054508 110 134760 017,114,117 000001
999
WASHER BRACKET TO CAB REAR PANEL
999
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
999
WASHER COMPRESSED AIR LINE TO BRACKET
999
WASHER MOUNTING PLATE TO BODY FLOOR
999
WASHER , Replaced By: N000125008443
999
WASHER EXHAUST MUFFLER TO STRAP
999
LOCK WASHER TAIL LAMP TO BRACKET
999
SPRING WASHER ALTERNATOR CONNECTION D+
999
SCREW COVER PLATE TO BRACKET
999
SCREW , Replaced By: N304017008021
999
NUT , Replaced By: N304032008006
999
SCREW , Replaced By: N007985005157
999
SCREW BATTERY CABLE MOUNTING AND MAIN CABLE HARNESS MOUNTING
999
SCREW
999
WASHER , Replaced By: N009021008213
999
WASHER BRACKET TO LEFT SIDE MEMBER
999
SCREW PUMP TO BRACKET
999
SCREW PIPE CLAMP
999
NUT
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
