Поз.
Артикул
Описание
329
THREADED UNION , Replaced By: A6999900283
329
FITTING , Replaced By: A0009905168
329
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
332
SEAL RING LINE CONNECTION
335
SCREW CONNECTION COMPRESSED AIR LINE TO WHEEL HUB, Replaced By: N000000006458
335
THREADED CONNECTION COMPRESSED AIR LINE TO WHEEL HUB
338
LINE , Replaced By: A0005516156
338
TUBE FROM HIGH PRESSURE HOSE TO STEERING
341
GLAND , Replaced By: A0019901967
341
SEAL CONE LINE CONNECTION
344
UNION NUT LINE CONNECTION
344
UNION NUT LINE CONNECTION, Replaced By: N000000006239
347
T-FITTING POWER STEERING
350
FITTING BEARING BRACKET TO AIR COMPRESSOR HOUSING
350
FITTING , Replaced By: A0809972472, +001A6999970189
353
COUPLING BEARING BRACKET TO AIR COMPRESSOR HOUSING
356
FITTING CUT-IN-VALVE-TO-STEERING-T-FITTING RETURN LINE
359
SEAL RING AIR COMPRESSOR,CONNECTION: "10"
362
SCREW CONNECTION LINE CONNECTION
365
TUBE FROM HIGH PRESSURE HOSE TO STEERING, LENGTH AVAILABLE: 3000 MM
365
LINE , Replaced By: A0005516256
368
UNION NUT LINE CONNECTION
371
GLAND LINE CONNECTION
374
FITTING CUT-IN-VALVE-TO-STEERING-T-FITTING RETURN LINE
377
SEAL RING VALVE TO VALVE,K 025179
380
UNION NUT LINE CONNECTION, Replaced By: N000000006243
380
NUT LINE CONNECTION
383
GLAND , Replaced By: A0019901267
383
SEAL CONE LINE CONNECTION
386
FITTING CUT-IN-VALVE-TO-STEERING-T-FITTING RETURN LINE
389
FITTING STEERING GEAR DELIVERY LINE,CIRCUIT II
392
FITTING OIL LINE CONNECTION
392
FITTING , Replaced By: N003952015100
395
LINE , NOT USED
398
LINE SUCTION LINE TO OIL PUMP
401
HOSE RETURN, FROM STEERING TO OIL TANK, ORDER BY THE METER
401
HOSE , Replaced By: A3859971582
401
HOSE , Replaced By: A6999971182
404
CLAMP , Replaced By: N000000000667
404
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
407
BANJO UNION. LINE (SUCTION LINE),FROM OIL TANK TO PUMP
407
LINE , Replaced By: A6254607388
410
HOLLOW SCREW SUCTION LINE TO OIL PUMP
413
SEAL RING AIR COMPRESSOR,CONNECTION: "10"
416
FITTING POWER STEERING PUMP TO BEARING FLANGE
419
SEAL RING POWER STEERING PUMP TO BEARING FLANGE
999
LINE12 MM, ORDER BY THE METER4 691315
999
LINE FROM POWER STEERING PUMP TO CUT-IN VALVE
999
LINE FROM POWER STEERING PUMP TO CUT-IN VALVE
999
PIPE CUT-IN-VALVE-TO-STEERING-T-FITTING RETURN LINE
