Поз.
Артикул
Описание
107
LEVER INJECTION PUMP CONTROL
110
BALL PIVOT ROD TO INJECTION PUMP LEVER
113
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
116
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
116
NUT , Replaced By: N913023006001
119
SCREW , Replaced By: N914146006102
122
ROD ACCELERATOR CONTROL
125
NUT SPRING-LOADED PUSH ROD
128
NUT L.H. THREAD
131
BALL SOCKET PULL ROD TO LEVER
134
BALL SOCKET ACCELERATOR CONTROL
137
CIRCLIP. SECURING CLIP BALL SOCKET TO ROD
140
SEAL RING MODULATION PRESSURE CONTROL
143
BRACKET CONTROL
146
MOTOR SERVOMOTOR
149
LEVER FINAL CONTROL ELEMENT
152
BALL PIVOT
155
SEAL RING MODULATION PRESSURE CONTROL
158
NUT HEATING PIPE TO BRACKET
161
SCREW. HEXAGON HEAD BOLT BUZZER TO WINDOW LEVEL GIRDER M6X25
164
NUT , Replaced By: N913023006001
164
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
167
GROMMET ACTUATOR TO BRACKET
167
GROMMET , Replaced By: A1029970081
170
SPACER TUBE OIL LINE TO BRACKET,K 093236
173
SCREW. HEXAGON HEAD BOLT BUZZER TO WINDOW LEVEL GIRDER M6X25
176
WASHER ACTUATOR TO BRACKET
179
HEXAGON HEAD BOLT. SCREW BRACKET TO ENGINE HOUSING M 14X20
182
BALL PIVOT ROD TO INJECTION PUMP LEVER
185
NUT , Replaced By: N913023006001
185
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
