Поз.
Артикул
Описание
10
DOOR SHELL RIGHT
10
DOOR SHELL , Replaced By: A1157301205
15
PANELLING RIGHT REAR DOOR
18
SCREW
23
DOOR LOCK RIGHT
30
PULL ROD RIGHT, FROM CHASSIS: 010 083019 110 211691 017,117 000001
38
CLIP
38
CLIP , Replaced By: A0069886378
42
DOOR LOCKING DEVICE RIGHT
46
LOCK PULL ROD TO DOOR LOCK
53
LOCK PULL ROD TO DOOR LOCK
55
RIVET UPPER PART
55
RIVET , Replaced By: A0009906092
56
RIVET , Replaced By: A0009905548
56
WASHER LOWER PART
57
LOCK PULL ROD TO DOOR LOCK
62
NUT RETAINER , Replaced By: A0009907191
62
NUT RETAINER , Replaced By: A3229900091
65
SCREW
68
EDGING RIGHT
70
CLIP
70
CLIP , Replaced By: A0069886378
80
LOCKING EYE RIGHT, FROM CHASSIS: 010 031987 ALSO INSTALLED ON: 026127-026384 110 071329 ALSO INSTALLED ON: 057116-057347
82
SCREW
86
PLATE 0.5 MM, FROM CHASSIS: 010 031987, ALSO INSTALLED ON: 026127-026384 110 071329, ALSO INSTALLED ON: 057116-057347
89
PLATE
98
INTERIOR HANDLE ASSEMBLY RIGHT, FROM CHASSIS: 010 083019, ALSO INSTALLED ON: 055487-055613 110 211691, ALSO INSTALLED ON: 137775-138117 017,117 000001
102
SLEEVE , FROM CHASSIS: 010 083019 110 211691 017,117 000001
105
LOCK. WASHER ELECTRIC MOTOR TO BRACKET
108
NUT RETAINER , Replaced By: A3229900091
111
ESCUTCHEON RIGHT
113
SEAL
120
INSERT RIGHT
122
KNOB , 023 116973 033 048510 123 097280 130 120563
125
DOOR HANDLE OUTSIDE RIGHT
130
PIN
133
PAD FRONT RIGHT
136
PAD REAR RIGHT
138
DISC SPRING
141
DOOR CHECK
143
ROLLER , Replaced By: A3147230068
143
ROLLER
145
PIN
147
WASHER DOOR CHECK TO FRONT PANEL PILLAR
150
LOCK
158
GLASS PANE RIGHT
163
SEAL RIGHT,FIXED WINDOW
167
SEAL , FROM CHASSIS: 010 076074 110 193042 017,117 000001
167
SEAL , Replaced By: A1167250198
170
WINDOW STAYBAR RIGHT
176
WINDOW RUN RIGHT
181
LOCK. WASHER ELECTRIC MOTOR TO BRACKET
183
SEALING SECTION 2240 MM, ORDER BY THE METER
185
WINDOW RUN 2275 MM LONG
187
CLIP
189
SEAL , FROM CHASSIS: 010 076074 110 193042 017,117 000001
189
SEAL , Replaced By: A1167250198
202
WINDOW REGULATOR RIGHT, FROM CHASSIS: 010 046471 110 111771
207
SPRING , Replaced By: A0007680734
207
SPRING
212
WINDOW REGULATOR RAIL RIGHT,100000
217
WINDOW REGULATOR RAIL RIGHT
223
REPAIR KIT
223
REPAIR KIT , Replaced By: A1237200114
228
CRANK OPERATED WINDOW RIGHT
231
RETAINING RAIL
239
RUBBER MOULDING
240
RUBBER MOULDING 290 MM, 100001
254
CRANK
270
PAD , Replaced By: A1237600020
270
COVERING , Replaced By: A1237600120
270
COVERING , STATE COLOR NUMBER WHEN ORDERING
277
WASHER
279
SEALING RAIL 2200 MM
280
SEALING RAIL OUTSIDE, FROM CHASSIS 011,060,062 100001
289
CLIP
291
CLIP
999
SPRING , Replaced By: A0007680905
999
WASHER , NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIR KIT
999
WASHER , NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIR KIT
999
SCREW , Replaced By: A1409843029
999
NUT RETAINER
999
NUT RETAINER , Replaced By: A0009907191
999
CLIP , Replaced By: A0039884178
999
EDGING
999
SEAL , Replaced By: A1157251298
999
WINDOW RUN LEFT
999
WINDOW REGULATOR LEFT, FROM CHASSIS: 000,002,010 046471 015 047683 100,102,110 111771 103,112 112413 115 051671 005,017,105,107,108,117,119 000001
999
CRANK , FROM CHASSIS: 000,002,010 046471 015 047683 100,102,110 111771 103,112 112413 115 051671 005,017,105,107,108,117,119 000001, Replaced By: A1237600102
999
INSERT LEFT
999
ESCUTCHEON LEFT
999
WASHER
999
SLIDE , Replaced By: A1155860072
999
REPAIR KIT , Replaced By: A1145860172
999
REPAIR KIT CONVERSION OF REAR DOOR
999
GARNISH MOULDING FRONT RIGHT
999
GARNISH MOULDING FRONT LEFT
999
GARNISH MOULDING LEFT
999
WELT , Replaced By: A1147300180
999
GARNISH MOULDING
999
REPAIR KIT , Replaced By: A1237200114
999
RETAINING RAIL
999
LOCKING EYE LEFT
999
PLATE 1.5 MM, FROM CHASSIS: 010 031987, ALSO INSTALLED ON: 026127-026384 110 071329, ALSO INSTALLED ON: 057116-057347
999
DOOR SHELL , Replaced By: A1157301105
999
PANELLING LEFT REAR DOOR
999
WINDOW STAYBAR LEFT
999
DOOR LOCK LEFT,LESS DOOR INNER LOCK
999
WINDOW REGULATOR RAIL LEFT, UP TO CHASSIS: 015,115 200000 110 400000
999
WINDOW REGULATOR RAIL LEFT, FROM CHASSIS: 015,115 200001 110 400001
999
PANELLING LEFT, STATE COLOR NUMBER WHEN ORDERING
999
DOOR LOCKING DEVICE LEFT
999
PANELLING LEFT
999
DOOR SHELL LEFT
999
WEATHERSTRIP LEFT
999
EDGE GUARD SECTION LEFT, STATE COLOR NUMBER WHEN ORDERING NO LONGER INSTALLED ON 005,105,108
999
CRANK OPERATED WINDOW LEFT, DELIVER ADDITIONALLY:1X 115 730 05 45 UP TO CHASSIS: 015,115 200000 110 400000 010,112 UNTIL PRODUCTION STOP
999
PULL ROD LEFT, FROM CHASSIS: 000,002,010 083019 ALSO INSTALLED ON 055487-055613 015 096865 ALSO INSTALLED ON 059434-049645 FROM CHASSIS: 100,102,103,110,112 211691 ALSO INSTALLED ON 137775-138117 115 104055 ALSO INSTALLED ON 064365-064536
999
SEAL LEFT
999
GLASS PANE LEFT
999
GLASS PANE , UP TO CHASSIS: 015,115 200000 110 400000, Replaced By: A1157301518, +001A1157300545
999
GLASS PANE , UP TO CHASSIS: 015,115 200000 110 400000, Replaced By: A1157301618, +001A1157300645
999
SEAL LEFT
999
GARNISH MOULDING LEFT
999
DOOR HANDLE OUTSIDE LEFT
999
INTERIOR HANDLE ASSEMBLY LEFT, FROM CHASSIS: 010 083019, ALSO INSTALLED ON: 055487-055613 110 211691, ALSO INSTALLED ON: 137775-138117 017,117 000001
999
PAD , Replaced By: A1157660205
999
PAD LEFT
999
CLIP , FROM CHASSIS 011,060,062 100001
999
SEAL INSIDE 4000 MM
999
SCREW
999
WASHER , Replaced By: N900055008001
999
WASHER , Replaced By: N000125004319
999
WASHER BRACKET TO SUPPORT
999
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
999
SCREW , UP TO CHASSIS: 017 029988 114 000523 117 064694
999
SCREW COVER PLATE TO BRACKET
999
SCREW , Replaced By: N304017006034
999
TOOTHED WASHER CABLE TO FUSE BOX
999
TOOTHED WASHER MASKED STOP LAMP
999
SHEET METAL SCREW ANTENNA CABLE TO REAR INSIDE PILLAR
999
SCREW
999
SCREW ,K 062140, Replaced By: N007985006580
999
SCREW APPARATUS PLATE TO CAB,K 062140
999
SCREW
999
SCREW
999
SCREW COVER PLATE TO COVER PLATE M 6 X 10
999
NUT , Replaced By: N913023006001
999
LOCK , UP TO CHASSIS: 005,007,008,015,017 207357 011 101648 060 102313 062 101808
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
999
NUT CONTROL UNIT TO BRACKET M 92884-0600D
999
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
999
SHEET METAL SCREW COVERING TO OUTSIDE CENTRAL PIECE
