Поз.
Артикул
Описание
6
ACCELERATOR PEDAL
15
LOCK RING
16
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
16
SPRING WASHER , Replaced By: N000137008212
17
WASHER , Replaced By: N000125008443
17
WASHER EXHAUST MUFFLER TO STRAP
18
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
18
SCREW , Replaced By: N304017008016
19
SPACER TUBE CONTROL SHAFT, 043 FROM CHASSIS 002067
27
SCREW COVER PLATE TO BRACKET
28
SPRING WASHER LICENSE PLATE TO BRACKET
38
SHAFT
44
SPRING
45
ROD FROM ANGULAR LEVER TO THROTTLE ACTUATOR
45
ROD , Replaced By: A1020701075
47
BOOT , Replaced By: A1163010297
47
BOOT BEARING TO FIRE WALL
50
BEARING BRACKET
51
SCREW COVER PLATE TO COVER PLATE M 6 X 10
51
SCREW , Replaced By: N304017006034
52
LEVER
53
BUSHING
55
LOCK PLATE RELEASE LEVER TO SHAFT
60
SHAFT , UP TO CHASSIS: 020 071390, ALSO INSTALLED ON: 071392,071396,071400,071402,071416. 024,025 068051, ALSO INSTALLED ON: 068099,068265 024,025 068051, EXCEPT FOR: 055714,055888,057629,058694,066624,066628,066632,066803,067088,067089,067410,067542,067578-067580, 067860-067862,067865,067924,067928-067943,067945,067948,067952,067953,067955-067969,067971-068001, 068005,068007-068019,068024,068026-068029,068031-068033,068035-068048,068050.
61
SPACER RING CONTROL SHAFT TO ENGINE
63
SPRING
65
JOINT BALL , Replaced By: A1263010485, +001A1163010150
66
SPACER RING CONTROL SHAFT TO ENGINE
67
LOCK PLATE
84
ROD , Replaced By: A1100700275
84
ROD
85
NUT TACHOGRAPH TO BRACKET
86
BALL SOCKET , Replaced By: A0009918922
86
BALL SOCKETTO 102 070 09 75, Replaced By: A0009930461
100
ROD , UP TO CHASSIS: 072 100019 073 100038
102
BALL SOCKET
102
END PIECE , Replaced By: A0009918822
103
NUT TACHOGRAPH TO BRACKET
104
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
999
COTTER PIN
999
RUBBER BUFFER
999
BUSHING
999
STOP
999
ACCELERATOR PEDAL , UP TO CHASSIS: 000,002,010 103904 015 131402 100,102,103,110,112 273248 115 137906, Replaced By: A1233000204, +001A1249888678
999
ACCELERATOR PEDAL , Replaced By: A1233000204
999
BOOT , Replaced By: A1163010297
999
BEARING
999
ACCELERATOR PEDAL
999
BOOT , UP TO CHASSIS: 020 014009 024 015678 028 015056 032,033 013400
999
SHAFT
999
ROD , FROM CHASSIS: 073 100039
