Поз.
Артикул
Описание
5
HORN HIGH NOTE, 123 A 217232 123 F 029182 126 A 103786
5
HORN , 123 A 217231 123 F 029181 126 A 103785, Replaced By: A0035425720, +001A1265401673
5
HORN LOW NOTE
5
HORN , 123 A 217231 123 F 029181 126 A 103785, Replaced By: A0035425620, +001A1265401573
5
HORN , Replaced By: A0035426520
5
HORN , Replaced By: A0035426420
5
HORN , Replaced By: A0025421020, +001A0025420920, +001A0005421040
5
HORN , Replaced By: A0025420920, +001A0025421020, +001A0005421040
5
HORN , Replaced By: A0025421020, +001A0025420920, +001A0005421040
5
HORN , Replaced By: A0025420920, +001A0025421020, +001A0005421040
7
BRACKET
9
BRACKET RIGHT, 123 A 217232 123 F 029182 126 A 103786
9
BRACKET LEFT, 123 A 217231 123 F 029181 126 A 103785
9
BRACKET RIGHT, 123 A 217231 123 F 029181 126 A 103785
9
BRACKET LEFT, 123 A 217232 123 F 029182 126 A 103786
13
BRACKET
13
BRACKET , 108.016 027165 108.018 028154 108.019 028685 109.016 001818 109.018 001970 108.057,058,067,068,109.056,057 FROM PRODUCTION START
13
BRACKET , 108.016 027164 108.018 028153 108.019 028684 109.016 001817 109.018 001969
20
BRACKET , 114.010 019879 114.005,006,007,008,015,017 018723 115.000,002,010 019864 115.015 017045 115.100,101,102,103,110,112 042285 115.115 019123
20
BRACKET , Replaced By: A1155402373
25
BRACKET RIGHT, 114.010 019880 114.005,006,007,008,015,017 018724 115.000,002,010 019865 115.015 017046 115.100,101,102,103,110,112 042286 115.115 019124
25
BRACKET LEFT, 114.010 019880 114.005,006,007,008,015,017 018724 115.000,002,010 019865 115.015 017046 115.100,101,102,103,110,112 042286 115.115 019124
35
BRACKET RIGHT
40
BRACKET LEFT
45
BRACKET LEFT
50
BRACKET RIGHT
60
BRACKET
60
BRACKET , Replaced By: A1105420740
70
SCREW , Replaced By: N304017008021
70
SCREW PIPE CLAMP
72
NUT
73
WASHER REAR FOGLAMP TO BRACKET
75
SCREW BRACKET TO CROSS CONNECTION STRUT
75
SCREW , Replaced By: N304017008034
80
SCREW , Replaced By: N304017008016
85
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
93
WASHER , Replaced By: N000125008443
93
WASHER EXHAUST MUFFLER TO STRAP
95
NUT
100
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
105
SCREW PIPE CLAMP
105
SCREW , Replaced By: N304017008021
110
SCREW , Replaced By: N304017008016
111
CABLE HARNESS
111
CABLE HARNESS
115
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
120
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
124
PLUG , Replaced By: A0095458828, +003A0015454426, +001A0105456628
125
WASHER REAR FOGLAMP TO BRACKET
130
SCREW COVER PLATE TO BRACKET
135
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
140
NUT BATTERY MOUNTING
145
RELAY
150
BRACKET
155
SHEET METAL SCREW BRACKET MOUNTING
160
SCREW
165
WASHER COVERING TO CYCLONE AIR TRAP
165
WASHER , Replaced By: N009021004207
170
LOCK WASHER T-FITTING TO BRACKET
175
NUT BOOT TO AIR DUCT AND TO AIR CLEANER
180
BRACKET
185
SCREW COVER PLATE TO COVER PLATE M 6 X 12
185
SCREW , Replaced By: N304017006018
190
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
195
NUT BATTERY MOUNTING
200
SHEET METAL SCREW BRACKET TO CAB FLOOR
205
CABLE HARNESS
205
CABLE HARNESS
205
CABLE HARNESS , 114.005,007,008,015,017 200001 114.011,023,060,062,072,073 100001 115.015,115 200001 115.100,102,103,110,112 400001 115.005,017,105,108,115,117,119 FROM PRODUCTION START
205
CABLE HARNESS
205
CABLE HARNESS
205
CABLE HARNESS , 114.005,007,008,015,017 200000 114.011,023,060,062,072,073 100000 115.015,115 200000 115.100,102,103,110,112 400000 115.005,017,105,108,115,117,119 NON INSTALLED
205
CABLE HARNESS
205
CABLE HARNESS
205
CABLE HARNESS
205
CABLE HARNESS
205
CABLE HARNESS
205
CABLE HARNESS , Replaced By: A1095401909
205
CABLE HARNESS , Replaced By: A1085402409
205
CABLE HARNESS , Replaced By: A1095401909
205
CABLE HARNESS , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A1145400209
205
CABLE HARNESS
210
PIN BUSHING HOUSING TRIPLE
210
PLUG , Replaced By: A0095458828, +003A0015454426, +001A0105456628
215
PIN BUSHING HOUSING 4-POLE, UP TO CHASSIS: 114.005,007,008,015,017 049721 114.010 044486 114.021 003371 114.022 007377 114.023 001704 FROM CHASSIS SEE 10948
215
PLUG , Replaced By: A0075450028, +004A0035452626, +001A0095452128
215
PLUG , Replaced By: A0045458628
215
PLUG TRIPLE
220
CABLE CONNECTOR ,760894
225
END-TYPE TERMINAL
230
CLIP FLEXIBLE SHAFT TO WHEELHOUSE, 086 007397 093 010089 183 NOT FOR SWEDEN 028930 183 SWEDEN F 001867 ALSO INSTALLED ON 028960 190 030466 ALSO INSTALLED ON 030442 193 005964 280 NOT FOR SWITZERLAND 009681 ALSO INSTALLED ON 009608,009626-009679 280 SWITZERLAND 009208 283 NOT FOR SWITZERLAND 019905 ALSO INSTALLED ON 019489,019510,019514,019524,019528-019534,019541,019543,019548-019550,019554-019575,019587,019590, 019593,019603,019604,019613,019614,019625-019638,019646,019649-019712,019715-019814,019821,019830- 019894,019899,019901. 283 SWITZERLAND F 000423 ALSO INSTALLED ON 021312,F 000333
230
CLIP TAIL LAMP CABLE HARNESS TO REAR LID
230
CLIP (HOSE LINE TO BRAKE BOOSTER)
230
CLIP
230
CLIP13 MM, Replaced By: A0129884678
230
CLIP FUEL LINE TO CAB CONSOLE
235
LOOM TIE , Replaced By: A0019974390
235
LOOM TIE , Replaced By: A0019974190
235
LOOM TIE , Replaced By: A0009974390
235
LOOM TIE TO MOUNT PLASTIC PIPING
235
LOOM TIE , UP TO CHASSIS: 108.012 UNTIL PRODUCTION STOP 108.016 042417 108.018,019 043374 109.016 002452
240
GROMMET ELECTRIC CABLE THRU FIRE WALL
250
GROMMET CAB ROOF
250
GROMMET , Replaced By: A0009972081
260
BRACKET
265
BRACKET
270
SHEET METAL SCREW BRACKET TO CAB FLOOR
275
SWITCH
275
SWITCH , Replaced By: A0015450011
275
SWITCH , Replaced By: A0015450011
280
SWITCH , Replaced By: A0015455507
280
SWITCH , Replaced By: A0015455507
280
SWITCH , Replaced By: A0015455507
280
SWITCH
280
SWITCH
285
ESCUTCHEON
290
KNOB
295
SCREW ELECTRIC CABLE TO HORN
300
LOCK WASHER T-FITTING TO BRACKET
999
COVERTO 009 545 88 28
999
ROUND PIN BUSHING4 MM2
