Поз.
Артикул
Описание
5
BEARING
8
SHIM BEARING BRACKET TO TUNNEL
11
GASKET
14
SCREW GEARSHIFT MECHANISM TO CONSOLE
17
SPACER TUBE
20
SHIFTING TUBE
23
PIN
26
SPRING SHIFTING TUBE
29
SHIFT LEVER 3RD AND 4TH SPEED
29
LEVER 5TH SPEED AND REVERSE
29
SHIFT LEVER 1ST AND 2ND SPEED
32
WASHER
36
SPACER WASHER
39
DISC SPRING
42
SPACER WASHER
45
BUSHING SHIFTING TUBE
48
BUSHING SHIFTING TUBE
51
BEARING
54
SCREW SOLENOID VALVE TO TRANSMISSION CASE TOP COVER M 6X32,002,003,006-009 4 263014-4 422632,034,134 4 276784-4 422632
57
SPRING WASHER LICENSE PLATE TO BRACKET
60
SHIFT LEVER
63
CLAMPING SLEEVE , Replaced By: N001481005017
63
CLAMPING SLEEVE
67
SPRING SHIFTING TUBE
70
COVER
73
BUSHING , 003 110322 007 099339 086 007515 093 011074 102,103 307216 105 267872 183 019925 190 025456 200 085537 280 003577 283 009004
76
BUSHING SHIFTING TUBE
79
SPRING
82
NUT
85
HANDLE , 108.016 071081 108.018,019 077838 111.024,025 005126
88
BOOT OPENING DOWNWARDS 180 MM, 030047 900768
91
LEVER 1ST,2ND,5TH SPEED AND REVERSE
91
LEVER 3RD AND 4TH SPEED
94
BUSHING , 102,103 219674 ALSO INSTALLED ON 219935,219936,220064,220096,220332. EXCEPT FOR 219267,219275,219283,219285,219287,219293,219296,219301,219302,219304,219307,219309,219313,219317, 219319-219321,219325,219326,219328-219331,219333,219335,219336,219338,219339,219341,219342,219346, 219347,219350,219351,219354,219357-219361,219363-219380,219384,219385,219387-219389,219391-219395, 219397,219399,219400,219402-219409,219411-219415,219417-219422,219424-219426,219428-219435,219437, 219439-219447,219449-219453,219459-219471,219473-219483,219485-219499,219502-219516,219520-219599, 219601-219673. 183 014172 ALSO INSTALLED ON 014174-014198,014203,014209,014215,014221,014225,014231,014407,014486,014630.
97
SCREW SHIFT LEVER TO TRANSMISSION
100
WASHER COMPRESSED AIR LINE TO BRACKET
100
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
103
NUT BALL PIVOT TO LEVER
106
ROD 1ST AND 2ND SPEED, UP TO IDENT NO. 081665 ALSO INSTALLED ON 082970,083157,083184,083395,083434.
106
ROD 3RD AND 4TH SPEED, UP TO IDENT NO. 081665 ALSO INSTALLED ON 082970,083157,083184,083395,083434.
106
ROD 5TH SPEED AND REVERSE
109
END PIECE
109
END PIECE GEARSHIFT MECHANISM, 184087, 309.030-035,051-059 192298, 309.050 182066, 309.1
112
BUSHING FROM LEVER TO VALVE BODY ASSEMBLY
115
NUT
118
SPRING WASHER SHIFTING ROD TO BRACKET
118
SPRING WASHER , Replaced By: N000137010205
121
LOCK
121
PIN LOCK SHIFTING ROD
124
GUIDE PIVOT SHIFTING TUBE
127
WASHER
130
SNAP RING SHIFTING TUBE
133
LOCK
136
BUSHING
139
SLOTTED GATE
142
SCREW STOP PLATE TO BEARING BRACKET
145
SPRING WASHER SHIFTING CYLINDER TO YOKE
148
WASHER
151
LOCK
154
SCREW , Replaced By: N304017010055
154
SCREW , Replaced By: N304017010050
157
SPRING WASHER STEERING COLUMN BRACKET TO CAB
160
SCREW BRACKET TO TRANSMISSION CASE
163
SPRING WASHER CAB FLOOR
163
SPRING WASHER AIR COMPRESSOR LINE TO ENGINE,5 812731 - 5 8174215 936366 - 5 999999K 000001N 817422K 126820
166
BLIND CAP
169
SCREW 3/2-WAY SOLENOID VALVE TO BRACKET
172
SPRING WASHER LICENSE PLATE TO BRACKET
