Поз.
Артикул
Описание
5
BRAKE PRESSURE REGULATOR
5
BRAKE PRESSURE REGULATOR ,649391 P 000001
8
BRACKET BRAKE POWER REGULATOR
11
SCREW PROTECTIVE PLATE TO EXHAUST PIPE
11
SCREW , Replaced By: N304017008039
14
LEVER , Replaced By: A4604300023
14
LEVER
17
BUSHING BRAKE PEDAL
17
BUSHING , Replaced By: A1242920050
20
BALL PIVOT BOTTOM B13X5 MM
23
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
23
SCREW , Replaced By: N304017008027
26
BRACKET
29
WASHER EXHAUST MUFFLER TO STRAP
29
WASHER , Replaced By: N000125008443
32
SPACER TUBE
35
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
35
NUT , Replaced By: N913004008001
35
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
38
FITTED WASHER ADJUSTING LEVER TO BRACKET
41
CLIP RESERVOIR TO CAB FRONT PANEL
44
SCREW PIPE CLAMP
44
SCREW , Replaced By: N304017008021
47
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
47
SPRING WASHER , Replaced By: N000137008212
50
NUT
53
SPRING RELEASE SPRING
56
ROD , Replaced By: A4604300192
56
ROD LEVER TO CONSOLE
