Поз.
Артикул
Описание
5
HOSE (RETURN LINE),FROM STEERING TO OIL TANK
8
LINE , 031425 900871
8
LINE LOW PRESSURE, 031424 900870
11
PIPE , FOR UNION NUT AND GLAND,SEE UNIT MICROFICHE,MODEL 765.5
11
PIPE , FOR UNION NUT AND GLAND,SEE UNIT MICROFICHE,MODEL 765.5
14
HOSE CLAMP LINE MOUNTING
14
CLAMP , Replaced By: A0059970190
20
HOSE HIGH PRESSURE
20
HOSE HIGH PRESSURE, 031424 900870
22
RUBBER RING
22
RUBBER RING
23
DAMPING STRIP , 031425 900891
26
THREADED CONNECTION. SCREW CONNECTION OIL DISTRIBUTION
29
THREADED CONNECTION COMPRESSED AIR LINE TO WHEEL HUB
29
SCREW CONNECTION COMPRESSED AIR LINE TO WHEEL HUB, Replaced By: N000000006458
32
UNION NUT LINE CONNECTION, Replaced By: N000000006239
32
UNION NUT LINE CONNECTION
32
NUT. UNION NUT LINE CONNECTION
35
SEAL CONE LINE CONNECTION
35
CUTTING RING. GLAND LINE CONNECTION
35
GLAND , Replaced By: A0019901967
41
CLAMP PIPE ON FAN SHROUD
47
SCREW LICENSE PLATE TO BRACKET
47
SCREW , Replaced By: N304017006020
48
SPRING WASHER LICENSE PLATE TO BRACKET
49
NUT BALL PIVOT TO LEVER
50
LINE , Replaced By: A0004291001, +002A0019901967, +002N915017012100
50
LINE12 MM, ORDER BY THE METER4 691315
53
LINE , Replaced By: A0004290101, +002N003861010009, +002N915017010100
53
LINE GAS LINE 10X1,5, LENGTH AVAILABLE 3000 MM REPAIR WORK SUBJECT TO SAFETY CHECK
56
RUBBER RING , 022 002391 ALSO INSTALLED ON 002285,002389,002390. 042 001836 ALSO INSTALLED ON 001736,001813,001823,001828,001834,001835. 022 005200 EXCEPT FOR 005190-005192,005194-005199. 042 004221 EXCEPT FOR 004213,004215-004218,004220.
59
BRACKET , 031425 900871
62
SCREW COVER PLATE TO COVER PLATE M 6 X 12
65
SCREW COVER PLATE TO BRACKET
68
NUT BALL PIVOT TO LEVER
71
SPRING WASHER LICENSE PLATE TO BRACKET
75
CLAMP LINES TO BRACKET, 031425 900891
78
FITTING (PARTS KIT),LINE RUPTURE
78
FITTING (PARTS KIT),LINE RUPTURE
999
PIPE LINE FROM CHECK VALVE DISTRIBUTOR TO SUPPLY TANK 500 MM, ORDER BY THE METER 114.010 FROM CHASSIS 031062,114.015,017 FROM CHASSIS 033609,114.021 FROM CHASSIS 001552,114.022 FROM CHASSIS 000843,114.023 FR OM CHASSIS 000001 115.010 FROM CHASSIS 034113,115.015 FROM CHASSIS 032215 114.010,021,022 UNTIL PRODUCTION STOP, 114.011 UP TO CHASSIS 108425, 114.015,017 UP TO CHASSIS 245853, 114.023 UP TO CHASSIS 100866 AND FOOTN.63
