Поз.
Артикул
Описание
5
LINE VACUUM LINE, UP TO IDENT NO. 941505 EXCEPT FOR 899081-941503 ONLY WITH OM601/OM602 ENGINE
5
LINE ,649391 P 000001689591
8
NUT
11
PLASTIC PIPE. HOSE (VACUUM LINE) FROM ENGINE TO BRAKE BOOSTER 440 MM
14
VALVE (CHECK VALVE)
14
VALVE , Replaced By: A0004316107
17
VALVE (CHECK VALVE), Replaced By: A0004316407
17
VALVE BRAKE BOOSTER ASSEMBLY
23
DAMPING RING
24
VALVE (CHECK VALVE)
58
ACCUMULATOR ,052674
61
GROMMET LINE MOUNTING 19/13 MM
64
CONNECTOR BRAKE BOOSTER ASSEMBLY
67
BRACKET , 052674 903528
73
SCREW , 052674 903528
73
SCREW LOCK SPRING TO CROSS MEMBER
76
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
76
NUT BALL PIVOT TO LEVER
79
SPRING WASHER LICENSE PLATE TO BRACKET
82
SPACER TUBE POWER CYLINDER TO LEVER
82
SPACER TUBE TWO-WAY VALVE TO BRACKET
