Поз.
Артикул
Описание
17
ELEMENT CO-DRIVER'S DOOR, 123.053 024919 153 000547 243 011304
20
CONTROL ROD
23
SWITCH (ON THE LEFT IN CASE OF L.H.D.,ON THE RIGHT IN CASE OF R.H.D.), IN CASE OF R.H.D.,TURN SHIFTING ROD BY 180 DEGS. 107.022,042 FROM PRODUCTION START,107.023 FROM CHASSIS 009633,107.024 FROM CHASSIS 007327 CONTINUED,SEE FOOTNOTE 059,060,061
26
SHEET METAL SCREW MODULE TO HOUSING
26
SHEET METAL SCREW. TAPPING SCREW INSTRUMENT PANEL ON WAIST RAIL 4.2X22,V 202043
26
SHEET METAL SCREW REFLECTOR TO BUMPER
29
ADHESIVE TAPE *** 4X9X45 MM, ORDER BY THE METER
32
CLAMP
35
BRACKET FRONT DOOR VACUUM SWITCH
38
SHEET METAL SCREW , Replaced By: N000000000453
38
SHEET METAL SCREW MODULE TO HOUSING
41
WASHER BRACKET TO SUPPORT
44
ELEMENT CO-DRIVER'S DOOR, 123.053 024919 153 000547 243 011304
47
CONTROL ROD
50
LOCK
53
LOCK PLATE , 000 000032 003 000013 007 000799 086 006409 093 007546 102,103 000031 105 000017 183 013075 190 019713 283 001214
56
SHEET METAL SCREW OIL LINE MOUNTING
59
WASHER BOOT TO CAB FLOOR
62
ELEMENT
65
SPRING , 114.010 FROM CHASSIS 025756,114.015,017 FROM CHASSIS 026340,114.021 FROM CHASSIS 000169,114.022 FROM CHASSIS 000026 115.010 FROM CHASSIS 027738,115.015 FROM CHASSIS 025224,115.110,112 FROM CHASSIS 060732,115.115 FROM CHASSIS 027945
68
LOCK PLATE
71
SHEET METAL SCREW , Replaced By: N007981004233
71
SHEET METAL SCREW BRACKET TO FLOOR PLATE, Replaced By: N000000000460
71
SHEET METAL SCREW BRACKET TO FLOOR PLATE
74
TANK
77
SEAL VACUUM SUPPLY TANK
80
CLIP
83
ELEMENT
86
BRACKET
89
SHEET METAL SCREW , Replaced By: N000000000459
89
SHEET METAL SCREW , Replaced By: N007981004233
89
SHEET METAL SCREW BRACKET TO FLOOR PLATE, Replaced By: N000000000460
89
SHEET METAL SCREW FUEL STRAINER SCREEN TO FUEL TANK
89
SHEET METAL SCREW BRACKET TO FLOOR PLATE
92
WASHER BRACKET TO SUPPORT
95
SPRING
98
BUSHING , 000 194867 003 101568 007 085543 102,103 232424 105 226121 200 021073
101
VALVE , FROM CHASSIS: 010 060996 110 152519
101
VALVE BELOW INSTRUMENT PANEL
104
HOSE TO ELEMENT AT FRONT SEAT
107
HOSE *** 30 MM
113
HOSE ORDER BY THE METER
116
HOSE , Replaced By: A0001581435
116
PIPE LINE FROM CHECK VALVE DISTRIBUTOR TO SUPPLY TANK 500 MM, ORDER BY THE METER 114.010 FROM CHASSIS 031062,114.015,017 FROM CHASSIS 033609,114.021 FROM CHASSIS 001552,114.022 FROM CHASSIS 000843,114.023 FR OM CHASSIS 000001 115.010 FROM CHASSIS 034113,115.015 FROM CHASSIS 032215 114.010,021,022 UNTIL PRODUCTION STOP, 114.011 UP TO CHASSIS 108425, 114.015,017 UP TO CHASSIS 245853, 114.023 UP TO CHASSIS 100866 AND FOOTN.63
119
HOSE FROM VACUUM SWITCH ON RIGHT FRONT DOOR TO DISTRIBUTOR ON RIGHT FRONT FLOOR 2000 MM, ORDER BY THE METER ORDER BY THE METER
122
HOSE GREY-YELLOW,FROM VACUUM DISTRIBUTOR IN ENGINE COMPARTMENT TO SUPPLY TANK, ORDER BY THE METER
122
HOSE FROM VACUUM SWITCH ON LEFT FRONT DOOR TO DISTRIBUTOR ON RIGHT FRONT FLOOR 3800 MM, ORDER BY THE METER
125
PIPE LINE FROM CHECK VALVE DISTRIBUTOR TO SUPPLY TANK 500 MM, ORDER BY THE METER 114.010 FROM CHASSIS 031062,114.015,017 FROM CHASSIS 033609,114.021 FROM CHASSIS 001552,114.022 FROM CHASSIS 000843,114.023 FR OM CHASSIS 000001 115.010 FROM CHASSIS 034113,115.015 FROM CHASSIS 032215 114.010,021,022 UNTIL PRODUCTION STOP, 114.011 UP TO CHASSIS 108425, 114.015,017 UP TO CHASSIS 245853, 114.023 UP TO CHASSIS 100866 AND FOOTN.63
125
HOSE , Replaced By: A0001581435
128
CLIP MAIN CABLE HARNESS TO FRONT FLOOR
131
CLIP
134
CLIP , FROM CHASSIS: 034089 ALSO INSTALLED ON: 033673,033706,033709,033716,033736,033765,033914,033922,033926,033930,033931,033934,033936,033938, 033939,033941-033951,033953,033955,033956,033959,033960,033962,033964,033966,033967,033969-033998, 034000-034010,034012-034022,034024-034087.
134
CLIP (HOSE LINE TO BRAKE BOOSTER)
137
HOSE *** 30 MM
140
BRANCH-OFF FITTING
143
BRANCH-OFF FITTING
