Поз.
Артикул
Описание
5
WINDOW GUIDE LEFT
5
WINDOW GUIDE RIGHT
8
SEAL
11
GUIDE RAIL LEFT
11
GUIDE RAIL RIGHT
14
BRACKET
17
SCREW
20
WINDOW RUN LEFT
20
WINDOW RUN RIGHT
23
SCREW COVER PLATE TO BRACKET
23
SCREW PUMP TO BRACKET
26
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
29
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
32
NUT , Replaced By: N304032008006
35
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
38
WASHER , Replaced By: N000125008443
47
SCREW STEERING COLUMN MOUNTED SWITCH TO STEERING COLUMN BRACKET M4X10
47
SCREW , Replaced By: N007985004107
50
SPRING WASHER ALTERNATOR CONNECTION D+
53
PLATE LEFT INSIDE,LESS HOLE
56
PLATE , Replaced By: A1077200211
59
GUIDE RAIL REAR RIGHT
59
GUIDE RAIL REAR LEFT
62
SLIDE
65
RING
68
SCREW , 042 001267
74
EXPANSION PLUG
77
SCREW DOOR HANDLE TO DOOR
80
FITTED WASHER
80
WASHER , Replaced By: N000988008024
86
CRANK OPERATED WINDOW , Replaced By: A1077201118
86
CRANK OPERATED WINDOW , Replaced By: A1077201218
86
CRANK OPERATED WINDOW RIGHT FRONT DOOR
86
CRANK OPERATED WINDOW LEFT FRONT DOOR
89
SLIDE , 022 003702 023 011757 024 017974 042 002943 043 012995 044 040440
95
SLIDING JAW BETWEEN GUIDE JAW AND GLASS PANE
95
PAD , Replaced By: A2087200042
101
WATER DEFLECTOR RAIL RIGHT
101
WATER DEFLECTOR RAIL LEFT
113
COMBINATION BOLT BATTERY FRAME TO CONSOLE, TOP
116
STOP BOTTOM
128
STOP TOP
173
SEALING RAIL , TO BE ADAPTED DURING ASSEMBLY, Replaced By: A1237250265
173
SEALING RAIL INSIDE LEFT AND RIGHT
176
SEALING RAIL LEFT INSIDE
176
SEALING RAIL RIGHT INSIDE
179
CLIP
179
CLIP
