Поз.
Артикул
Описание
5
ELECTRIC MOTOR , 023 008931 024 10/50,12/52 004142 024 20/60,22/62 004138 043 10/50,12/52 010970 043 20/60,22/62 010969 044 015095 ALSO INSTALLED ON 014731,014740,014747,014748,014751,014752.
11
CRANK
23
SLEEVE , 022 000008 023 009909 024 008069 042 000009 043 011545 044 021340
32
RUBBER RING SIGNAL LAMP TO ROOF
35
NUT BATTERY MOUNTING
35
NUT CYLINDER TO BRACKET TO0002902112
38
TOOTHED WASHER MASKED STOP LAMP
41
SLEEVE , 022 000008 023 009909 024 008069 042 000009 043 011545 044 021340
44
LINKAGE
47
ROD
50
RUBBER RING
50
RUBBER RING , Replaced By: A0009870741
53
PAD
56
SCREW COVER PLATE TO BRACKET
65
TOOTHED WASHER MASKED STOP LAMP
68
SCREW COVER PLATE TO COVER PLATE M 6 X 12
68
SCREW , Replaced By: N304017006018
71
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
74
WASHER COMPRESSED AIR LINE TO BRACKET
74
WASHER , Replaced By: N009021006208
77
SCREW COVER PLATE TO BRACKET
80
SPRING WASHER LICENSE PLATE TO BRACKET
83
WASHER WIPER BEARING
86
NUT WIPER ARM ON SPINDLE
89
NUT WIPER ARM ON SPINDLE
92
WIPER ARM RIGHT, 023 006504 024 001070 043 009921 044 010624 023 008792 024 003826
92
WIPER ARM LEFT, 023 006504 024 001070 043 009921 044 010624 023 008792 024 003826
95
WIPER BLADE RIGHT
98
WIPER RUBBER RIGHT
101
NUT
101
NUT , Replaced By: N304035008001
104
WASHER
