54 ELECTRICAL EQUIPMENT AND INSTRUMENTS
001 ADDITIONAL HEATER,RANGE OF ELECTRICAL PARTS (FOR TYPES 129,140 SEE STANDARD VERS IL.3

Mercedes N007976004215 - Саморез

230 USA 123.023

54 ELECTRICAL EQUIPMENT AND INSTRUMENTS - 001 ADDITIONAL HEATER,RANGE OF ELECTRICAL PARTS (FOR TYPES 129,140 SEE STANDARD VERS IL.3

Поз.
Артикул
Описание
5
A1236701380
REAR WINDOW PANE ELECTRICALLY HEATED, SINGLE-SHEET SAFETY GLASS, HEAT-ABSORBING, 023 016459 033 012020 123 008855 130 014466
5
A1236701580
REAR WINDOW PANE HEAT-ABSORBING,COMPOUND GLASS
8
A1265401081
PLUG SOCKET UNIPOLAR
8
A0045458428
PLUG , Replaced By: A1265401081
11
A1236700239
SEALING FRAME REAR WINDOW PANE
14
A0029877725
PLASTIC SECTION
17
A1236781030
FRAME RIGHT
17
A1236780930
FRAME LEFT
20
A1236780330
FRAME BOTTOM
23
A1236780237
JOINT COVER TOP
26
A1236780137
JOINT COVER BOTTOM
29
A1236780015
STOP REAR WINDOW PANE
32
N007976004215
SHEET METAL SCREW
35
N000433005304
WASHER BOOT TO CAB FLOOR
35
N000125005317
WASHER , Replaced By: N000433005304
