Поз.
Артикул
Описание
5
FRONT FENDER LEFT
5
FRONT FENDER RIGHT
8
FRONT FENDER LEFT
8
FRONT FENDER RIGHT
11
REPAIR KIT FRONT FENDER MOUNTING MATERIAL
14
RUBBER BUFFER
14
RUBBER BUFFER , Replaced By: A1269870139
17
LOCK BRACKET WITH MOTOR AND GEARING TO REAR PILLAR, 033 102015 123 329277 130 276372 133 008386 223 100392
20
COMBINATION BOLT FRONT FENDER TO SIDE MEMBER
23
SHEET METAL SCREW ELECTRIC CABLE THRU CAB FLOOR
23
COMBINATION BOLT BRACKET TO WINDOW LEVEL
23
TAPPING SCREW BRACKET TO CAB FLOOR
26
LOCK INSTRUMENT PANEL TO PANELLING
29
SHEET METAL SCREW FRONT FENDER TO BRACKET AT FRONT LATERAL STIFFENING
32
LOCK , Replaced By: A1269941345
32
LOCK INSTRUMENT PANEL TO COWL
35
COMBINATION BOLT FRONT FENDER TO FRONT PANEL PILLAR
38
SCREW FRONT FENDER TO FRONT PANEL PILLAR
38
SCREW , Replaced By: A2019900936
38
COMBINATION BOLT BRACKET TO FRAME
38
SCREW GUIDE TUBE BRACKET TO RADIATOR
41
LOCK FRONT FENDER TO WHEELHOUSE,TOP
44
COMBINATION BOLT
47
LOCK , Replaced By: A1269941345
47
LOCK INSTRUMENT PANEL TO COWL
50
SHEET METAL SCREW CABLE MOUNTING IN CABLE DUCT, NOT USED
53
GRILLE (VENTILATION SCREEN) LEFT
53
GRILLE (VENTILATION SCREEN) RIGHT
56
COMBINATION BOLT
59
CLIP FUEL LINE TO CAB CONSOLE
62
PANELLING UNDER FRONT BUMPER,CENTRAL
65
ADHESIVE TAPE (SEAL),BETWEEN OUTSIDE REAR PILLAR AND ROOF 560 MM, ORDER BY THE METER
68
PARTITION PANEL LEFT, 003 109846 007 098845 086 007460 093 010728 102,103 304110 105 266567 183 019765 190 024810 193 007800 200 082946 280 003502 283 008886
68
PARTITION PANEL RIGHT, 033 098665 130 265954 223 081900
74
SCREW FRONT FENDER PARTITION PANEL TO WHEELHOUSE, 033 098665 130 265954 223 081900
80
SEAL600 MM, 033 098665 130 265954 223 081900
86
SEALING CORD PAINT RUN-OFF HOLE IN REAR WINDOW OPENING, ORDER BY THE METER
