Поз.
Артикул
Описание
5
FRAME WITH DRAFT DEFLECTOR
5
FRAME , 023 195353 033 089127 123 247958 130 236138 223 033444, Replaced By: A1237803129, +001A1236903550
8
SCREW BOTTOM FRAME
11
RUBBER BUFFER
14
DRAFT DEFLECTOR ,A 232400
14
DRAFT DEFLECTOR , Replaced By: A1267800544, +001A1247820535, +001A1247820635, +002A1247820046
14
DRAFT DEFLECTOR , 023 005873 123 003641 130 005476A 232399, Replaced By: A1267800044, +001A1237822726, +001A1237822826
14
DRAFT DEFLECTOR , 023 005872 123 003640 130 005475, Replaced By: A1237800244, +001A1237840521
17
MOUNTING , Replaced By: A1247840221
17
MOUNTING , Replaced By: A1247840121
17
MOUNTING FRONT RIGHT
17
MOUNTING FRONT LEFT
20
MOUNTING LATERAL
23
LEVER LEFT
23
LEVER RIGHT
23
LEVER , Replaced By: A2017800138
26
SPRING LEFT
26
SPRING RIGHT
26
SPRING , Replaced By: A1247820635, +001A1247820046
26
SPRING , Replaced By: A1247820535, +001A1247820046
27
STAY
29
MOUNTING , 023 005872 123 003640 130 005475, Replaced By: A1236740521, +001A1267800544
29
MOUNTING CENTRAL
32
SEAL BOTTOM FRAME,FRONT
35
SEAL BETWEEN TOP AND BOTTOM FRAMES
38
CLIP
41
FOAM PLASTICS FRONT ROOF RAIL
44
INSULATION REAR
47
PAD
50
PLASTIC SECTION CABLE HARNESS TO ROOF RAIL
53
SHEET METAL SCREW
56
LOCK FRAME TO REINFORCEMENT FRAME
59
HEXAGON HEAD BOLT
59
SCREW , Replaced By: N910105006002
62
NUT RETAINER BOTTOM FRAME TO REAR LEFT AND RIGHT ROOF RAILS
65
COVER RAIL
65
COVER RAIL BOTTOM FRAME,FRONT, 023 049084 033 024844 123 034291 130 044426
68
SHEET METAL SCREW
71
RAIL RIGHT
71
RAIL LEFT
74
LOCK
77
RIVET
80
SCREW
83
SEAL480 MM
86
SLIDING RAIL LEFT
86
SLIDING RAIL RIGHT
165
SLIDING RAIL LEFT
165
SLIDING RAIL RIGHT
168
SCREW
172
SCREW , Replaced By: A1409900436
172
SCREW
187
HOSEWASSERABLAUF HINTEN 250 MM
999
CLEANER
999
CLEANER
