Поз.
Артикул
Описание
5
HOSE FROM FEED LINE TO FILTER 240 MM
5
HOSE DE-AERATION B8X12,5 218304 ORDER BY THE METER
5
HOSE FUEL LINE TO TANK 13.5 X 7.5 MM, ORDER BY THE METER
8
VALVE
11
FILTER , 100.012,014,016 001961 108.018 077635 114.011 006505 114.023 003980 115.010 076259
14
COVER , 100.012,014,016 001961 108.018 077635 114.011 006505 114.023 003980 115.010 076259
16
SHEET METAL SCREW , 100.012,014,016 001961 108.018 077635 114.011 006505 114.023 003980 115.010 076259
17
VALVE ,K 169122
17
VALVE ,K 169122
18
HOSE FROM FEED LINE TO FILTER 240 MM
18
HOSE DE-AERATION B8X12,5 218304 ORDER BY THE METER
18
HOSE FUEL LINE TO TANK 13.5 X 7.5 MM, ORDER BY THE METER
19
CLAMP
20
BREATHER PIPE
20
BREATHER PIPE
20
BREATHER PIPE
26
ACTIVATED CHARCOAL FILTER , Replaced By: A1234700259
26
ACTIVATED CHARCOAL FILTER
35
HOSE CLAMP HOSE FASTENING 9/13MM
