Поз.
Артикул
Описание
5
REAR FENDER LEFT
12
REINFORCEMENT LEFT
18
SIDE MEMBER LEFT
26
END PIECE LEFT
36
PILLAR LEFT
44
PILLAR CENTRAL LEFT
50
HINGE TOP LEFT, 012 FROM CHASSIS 000081,014 FROM CHASSIS 000024
57
BUSHING
63
HINGE PIN , Replaced By: A1157330015
63
PIN
69
GREASE NIPPLE
76
HINGE BOTTOM, 012 FROM CHASSIS 000081, 014 FROM CHASSIS 000024, 015 FROM CHASSIS 000015
103
PILLAR OUTSIDE LEFT
109
WHEELHOUSE REAR LEFT
116
WHEELHOUSE REAR OUTSIDE LEFT
124
ROOF RAIL INSIDE LEFT
129
STRUT
136
BOTTOM SPARE WHEEL WELL,LEFT
143
CLAMP ON LEFT SPARE WHEEL WELL PLATE
152
STRUT
999
PILLAR OUTSIDE RIGHT
999
REINFORCEMENT RIGHT
999
ROOF RAIL INSIDE RIGHT
999
WHEELHOUSE REAR RIGHT
999
PILLAR , 016 UP TO CHASSIS 049099, 018 UP TO CHASSIS 052477, 019 UP TO CHASSIS 052616, Replaced By: A1086300910
999
PILLAR , 016 UP TO CHASSIS 049099,018 UP TO CHASSIS 052477,019 UP TO CHASSIS 052616, Replaced By: A1086301010
999
PILLAR RIGHT
999
PILLAR RIGHT
999
ROOF RAIL LEFT
999
ROOF RAIL , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A1096300735
999
ROOF RAIL OUTSIDE LEFT
999
REAR FENDER RIGHT
999
SIDE MEMBER RIGHT
999
END PIECE RIGHT
999
RECESS SPARE WHEEL WELL,RIGHT
999
ROOF RAIL RIGHT
999
ROOF RAIL INSIDE RIGHT
999
ROOF RAIL OUTSIDE RIGHT
999
WHEELHOUSE REAR OUTSIDE RIGHT
999
HINGE PIN , Replaced By: A1157330015
999
HINGE TOP RIGHT, 012 FROM CHASSIS 000081, 014 FROM CHASSIS 000024, 015 FROM CHASSIS 000015
