Поз.
Артикул
Описание
12
CLUTCH PRESSURE PLATE , PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
15
SPRING
19
RELEASE LEVER , ON SPECIAL REQUEST, H.D. CLUTCH
25
PIN
29
CLAMPING SLEEVE
33
SPACER RING
37
NUTTO 001 250 03 04
37
NUT , Replaced By: A0002522772
41
PRESSURE SPRING CLUTCH PRESSURE PLATE
46
SLEEVE
49
THRUST WASHER
53
CLUTCH DISC SPLINE-SHAFT SECTION, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
57
SCREW BRACKET TO CROSS CONNECTION STRUT
57
SCREW , Replaced By: N304017008034
62
LOCK WASHER TAIL LAMP TO BRACKET
69
HYDRAULIC CLUTCH , 000,001,004,010,016 FROM CHASSIS 130558, 100,101,104,110,116 FROM CHASSIS 225648
73
SCREW PLUG
76
SEAL RING
100
HOUSING
103
STUD TAIL-, BRAKE-, AND TURN SIGNAL LIGHTS
112
HOUSING HYDRAULIC CLUTCH
118
COVER PLATE
153
BOOT
159
SEAL HOLDER
166
SCREW COVER PLATE TO COVER PLATE M 6 X 12
166
SCREW , Replaced By: N304017006018
172
SCREW , Replaced By: A0089907401
172
SCREW BRACKET TO SIDE MEMBER,K 168169
179
SPRING WASHER GROUND CABLE TO TRANSMISSION
244
RELEASE BEARING
250
BALL BEARING , 000,001,004,010,016 FROM CHASSIS 081441, 100,101,104,110,116 FROM CHASSIS 128634
262
RELEASE YOKE
274
SPRING
279
SNAP RING
286
SLAVE CYLINDER , 010 FROM CHASSIS 048977,012 FROM CHASSIS 108750 NOT FOR USE WITH MERCEDES-BENZ HYDRAULIC-AUTOMATIC CLUTCH
291
PIN
297
BOOT ,027649
304
VALVE
310
PROTECTIVE CAP , Replaced By: A0004217187
310
PROTECTIVE CAP ,5 962906
316
REPAIR KIT ,027649
336
ROD
343
NUT
343
NUT , Replaced By: N304035008001
348
SPRING
999
RIVET , NO LONGER AVAILABLE INDIVIDUALLY, BUT ONLY IN REPAIR KIT
999
CLUTCH LINING , Replaced By: A1085860025
999
CLUTCH LINING ON FLYWHEEL END, NOT FOR USE WITH MERCEDES-BENZ HYDRAULIC-AUTOMATIC CLUTCH NO LONGER AVAILABLE INDIVIDUALLY
999
BOOT
999
REPAIR KIT , 014 FROM CHASSIS 049462,021 FROM CHASSIS 049449,023 FROM CHASSIS 049723
999
BALL BEARING , 000,001,004,010,016 FROM CHASSIS 081441, 100,101,104,110,116 FROM CHASSIS 128634
999
REPAIR KIT ON CLUTCH END, NO LONGER AVAILABLE INDIVIDUALLY, BUT ONLY IN REPAIR KIT
999
RELEASE BEARING , ON SPECIAL REQUEST, H.D. CLUTCH
999
HYDRAULIC CLUTCH , 000,001,010 UP TO CHASSIS 130557, 100,101,110 UP TO CHASSIS 225647
999
WASHER BRACKET TO REAR CROSS MEMBER
999
SPRING WASHER LICENSE PLATE TO BRACKET
999
SPRING WASHER , Replaced By: N000137008212
999
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
999
SPRING WASHER CAB FLOOR
999
SPRING WASHER AIR COMPRESSOR LINE TO ENGINE,5 812731 - 5 8174215 936366 - 5 999999K 000001N 817422K 126820
999
SCREW HYDRAULIC CLUTCH TO ENGINE, 021,023 UP TO CHASSIS 086009
999
SCREW CONNECTOR TO EXHAUST MANIFOLD
999
SCREW COVER PLATE TO BRACKET
999
SCREW , Replaced By: N304017008021
999
SCREW , Replaced By: N304017012002
999
NUT
999
NUT STRAP TO SUPPORT,5 149419
999
SCREW PUMP TO BRACKET
999
SCREW PIPE CLAMP
999
SCREW RELEASE LEVER TO SHAFT, 024,026,027,028,121,122 5 095724 065,131,132 5 104252
999
LOCK WASHER FITTING TO BRACKET
