Поз.
Артикул
Описание
1
ACCELERATOR PEDAL
3
ACCELERATOR PEDAL
3
PAD , Replaced By: A1233000204
4
PAD , Replaced By: A1233000204
4
ACCELERATOR PEDAL
7
JOINT ,B 859430
10
CLIP
10
BRACKET , Replaced By: A1249888678
12
BEARING
20
CLIP PRE-GLOW TIME RELAY TO COWL
24
WASHER , UP TO CHASSIS: 017 029988 114 000523 117 064694
25
SHEET METAL SCREW
75
STOP
76
SEAL RING KICK-DOWN SWITCH
111
STOP
116
KICK-DOWN SWITCH , FROM CHASSIS: 011: 12/52 100001 007,008,015,017: 12/52 200001
117
NUT
120
BEARING BRACKET
121
STUD
122
SPRING WASHER
123
NUT
123
NUT , Replaced By: N304032010002
124
BUSHING
125
LEVER
128
HOSE FUEL LINE, ORDER BY THE METER
130
LOCK PLATE
131
SCREW BRACKET TO CROSS CONNECTION STRUT
131
SCREW , Replaced By: N304017008034
132
WASHER , Replaced By: N000125008443
132
WASHER EXHAUST MUFFLER TO STRAP
999
ROD , UP TO CHASSIS: 072 100019 073 100038
999
SHAFT
999
BOOT , UP TO CHASSIS: 020 014009 024 015678 028 015056 032,033 013400
999
ACCELERATOR PEDAL
999
BEARING
999
BOOT , Replaced By: A1163010297
999
ACCELERATOR PEDAL , UP TO CHASSIS: 000,002,010 103904 015 131402 100,102,103,110,112 273248 115 137906, Replaced By: A1233000204, +001A1249888678
999
STOP
999
BUSHING
999
BOOT BEARING TO FIRE WALL
999
RUBBER BUFFER
999
COTTER PIN
999
WASHER , Replaced By: N000125008443
999
SPRING WASHER , Replaced By: N000137008212
999
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
999
SCREW , Replaced By: N304017008016
999
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
