Поз.
Артикул
Описание
83
HOSE FROM PUMP TO STEERING
83
HOSE
85
HOSE FROM PUMP TO STEERING
85
HOSE FROM PUMP TO STEERING
92
CLAMP , Replaced By: A0004760436
92
BRACKET LINE MOUNTING 11 MM
94
CLAMP HOSE TO HOSE 20 MM
120
LINE FROM STEERING TO OIL TANK, 115.100,102,103,112 UNTIL PRODUCTION STOP 115.110 437598 115.115 260471 115.105,107,108,117,119 071837
120
LINE FROM STEERING TO OIL TANK
120
LINE FROM STEERING TO OIL TANK
132
LINE FROM STEERING TO OIL TANK, 115.105,107,117 102170 115.108,119 103576 115.110 455005 115.114 028561 115.115 310394
132
LINE FROM STEERING TO OIL TANK, 115.110 437599 115.115 260472 115.105,107,108,117,119 071838 115.100,102,103,112 UNTIL PRODUCTION STOP 115.105,107,117 102169 115.108,119 103575 115.110 455004 115.114 028560 115.115 310393
138
HOSE80 MM, ORDER BY THE METER
145
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
145
CLAMP , Replaced By: N000000000667
150
OIL TANK
150
OIL TANK
150
OIL TANK , 115.100,102,103,112 UNTIL PRODUCTION STOP 115.110 437598 115.115 260471 115.105,107,108,117,119 071837
150
OIL TANK , 115.105,107,117 102170 115.108,119 103576 115.110 455005 115.114 028561 115.115 310394
150
OIL TANK
150
OIL TANK
150
OIL TANK
154
SCREW
157
LOCK
160
FILTER
163
WASHER
167
SPRING
170
COVER
174
GASKET
180
LINE FROM OIL TANK TO PUMP
180
LINE FROM OIL TANK TO PUMP
180
LINE FROM STEERING TO OIL TANK
180
LINE FROM OIL TANK TO PUMP
184
LINE FROM OIL TANK TO PUMP
187
CLAMP
192
HOSE80 MM, ORDER BY THE METER
195
HOLLOW SCREW LINE TO OIL PUMP
198
SEAL RING SWITCH TO CASE COVER
202
RUBBER RING
202
RUBBER RING
207
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
207
CLAMP , Replaced By: N000000000667
213
NUT CYLINDER TO BRACKET TO0002902112
213
NUT BATTERY MOUNTING
217
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
224
BRACKET
227
BRACKET OIL TANK
230
NUT RETAINER , Replaced By: A0009909491
230
NUT RETAINER BOTTOM FRAME TO REAR LEFT AND RIGHT ROOF RAILS
234
SCREW COVER PLATE TO BRACKET
237
WASHER COMPRESSED AIR LINE TO BRACKET
237
WASHER , Replaced By: N009021006208
999
LOCK , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0049949241
999
CLAMP , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: N900288094102
999
NUT , Replaced By: A0019907051
999
LOCK
999
REPAIR KIT , Replaced By: A1075860246
999
STEERING BOX ASSEMBLY , Replaced By: A1164600801
999
STEERING BOX ASSEMBLY , Replaced By: A1164600901
999
STEERING BOX ASSEMBLY , Replaced By: A1074601701
999
STEERING BOX ASSEMBLY , Replaced By: A1074601801
999
OIL TANK , 115.110 437599 115.115 260472 115.105,107,108,117,119 071838 115.100,102,103,112 UNTIL PRODUCTION STOP 115.105,107,117 102169 115.108,119 103575 115.110 455004 115.114 028560 115.115 310393, Replaced By: A1154600783, +001A1154601524
999
HOSE , Replaced By: A1149973982
999
STEERING BOX ASSEMBLY , Replaced By: A1144602101
999
STEERING BOX ASSEMBLY , Replaced By: A1144602201
999
SCREW , Replaced By: A2019900801
999
SCREW STEERING TO FRAME
999
NUT
