Поз.
Артикул
Описание
2
REAR SEAT CUSHION , STATE COLOR NUMBER WHEN ORDERING
2
REAR SEAT CUSHION , Replaced By: A1159201220
15
CUSHION FRAME , FROM CHASSIS: 015 250811 017 038250 110 440114 114 006350 115 266006 117,119 075815
22
PAD , FROM CHASSIS: 015 250811 017 038250 110 440114 114 006350 115 266006 117,119 075815
28
CLIP COVER TO PAD
29
COVER , STATE COLOR NUMBER WHEN ORDERING
32
CLIP
35
BRACKET
44
BACKREST , STATE COLOR NUMBER WHEN ORDERING 000016
48
BACKREST
52
BACKREST FRAME , 034415
55
PAD
55
PAD , Replaced By: A1159241516
58
CLIP COVER TO PAD
60
COVER , STATE COLOR NUMBER WHEN ORDERING
62
LOCK PLATE
65
CLIP
67
SUPPORT
80
WASHER
82
NUT BALL PIVOT TO LEVER
999
BACKREST LESS COVER , Replaced By: A1159200304
999
SEAT CUSHION
999
SEAT CUSHION LESS COVER , Replaced By: A1159201022, +001A1159200250
999
BACKREST FRAME , UP TO CHASSIS: 010 038362 015 037125 110,112 087679 115 039985, Replaced By: A1159201032, +001A1159702030, +002A1159730820
999
REAR SEAT BACKREST , Replaced By: A1159200430
999
BACKREST LESS COVER
999
CUSHION FRAME , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO CHASSIS: 010 091777 015 112060 110,112 234177 115 118981, Replaced By: A1159200822
999
SEAT CUSHION , Replaced By: A1159200102
999
REAR SEAT BACKREST , Replaced By: A1159200004
999
BACKREST , Replaced By: A1159200004
999
CUSHION FRAME , Replaced By: A1159201022, +001A1159200150
999
PAD , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO CHASSIS: 010 091777 015 112060 110,112 234177 115 118981, Replaced By: A1159240914
999
COVER , Replaced By: A1159240914
999
COVER , Replaced By: A1159240516
999
PAD
999
SCREW
999
WASHER , Replaced By: N009021006208
999
WASHER COMPRESSED AIR LINE TO BRACKET
