Поз.
Артикул
Описание
1
DOOR SHELL RIGHT
1
DOOR SHELL , Replaced By: A1157301205
3
PANELLING RIGHT REAR DOOR
7
SCREW
10
DOOR LOCK RIGHT
13
PULL ROD RIGHT, FROM CHASSIS: 010 083019 110 211691 017,117 000001
15
CLIP
15
CLIP , Replaced By: A0069886378
17
DOOR LOCKING DEVICE RIGHT
20
LOCK PULL ROD TO DOOR LOCK
23
SPRING WASHER SHIFTING CYLINDER TO YOKE
24
RIVET UPPER PART
24
RIVET , Replaced By: A0009906092
25
RIVET , Replaced By: A0009905548
25
WASHER LOWER PART
28
CLIP
28
CLIP , Replaced By: A0069886378
30
LOCK PULL ROD TO DOOR LOCK
32
NUT RETAINER
35
NUT RETAINER , Replaced By: A0009907191
35
NUT RETAINER , Replaced By: A3229900091
37
SCREW , Replaced By: A1409843029
37
SCREW
40
EDGING RIGHT
45
LOCKING EYE RIGHT, FROM CHASSIS: 010 031987 ALSO INSTALLED ON: 026127-026384 110 071329 ALSO INSTALLED ON: 057116-057347
51
PLATE
57
INTERIOR HANDLE ASSEMBLY RIGHT, FROM CHASSIS: 010 083019, ALSO INSTALLED ON: 055487-055613 110 211691, ALSO INSTALLED ON: 137775-138117 017,117 000001
59
SLEEVE , FROM CHASSIS: 010 083019 110 211691 017,117 000001
62
LOCK. WASHER ELECTRIC MOTOR TO BRACKET
67
ESCUTCHEON RIGHT
69
SEAL
74
INSERT RIGHT
76
KNOB , 023 116973 033 048510 123 097280 130 120563
79
DOOR HANDLE OUTSIDE RIGHT
81
PIN
84
PAD FRONT RIGHT
86
PAD REAR RIGHT
89
DISC SPRING
91
DOOR CHECK
93
ROLLER , Replaced By: A3147230068
93
ROLLER
95
PIN
97
WASHER DOOR CHECK TO FRONT PANEL PILLAR
99
LOCK
105
GLASS PANE RIGHT
109
SEAL RIGHT,FIXED WINDOW
112
SEAL , FROM CHASSIS: 010 076074 110 193042 017,117 000001
116
WINDOW STAYBAR RIGHT
119
WINDOW RUN RIGHT
123
LOCK. WASHER ELECTRIC MOTOR TO BRACKET
130
SEAL , FROM CHASSIS: 010 076074 110 193042 017,117 000001
130
SEAL , Replaced By: A1157251298
130
SEAL , Replaced By: A1167250198
132
WINDOW REGULATOR RIGHT, FROM CHASSIS: 010 046471 110 111771
134
SPRING , Replaced By: A0007680734
134
SPRING
138
WINDOW REGULATOR RAIL RIGHT
140
REPAIR KIT
140
REPAIR KIT , Replaced By: A1237200114
143
CRANK OPERATED WINDOW RIGHT
152
CRANK
159
COVERING , STATE COLOR NUMBER WHEN ORDERING
159
PAD , Replaced By: A1237600020
159
COVERING , Replaced By: A1237600120
162
WASHER
164
SEAL INSIDE 4000 MM
168
SEALING RAIL , Replaced By: A1167250065
168
SEALING RAIL OUTSIDE, FROM CHASSIS 011,060,062 100001
169
CLIP
173
CLIP , FROM CHASSIS 011,060,062 100001
999
SPRING , Replaced By: A0007680905
999
WASHER , NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIR KIT
999
RUBBER MOULDING 290 MM, 100001
999
WASHER , NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIR KIT
999
SCREW
999
NUT RETAINER , Replaced By: A0009907191
999
CLIP , Replaced By: A0029884578
999
EDGING
999
WINDOW RUN LEFT
999
WINDOW REGULATOR LEFT, FROM CHASSIS: 000,002,010 046471 015 047683 100,102,110 111771 103,112 112413 115 051671 005,017,105,107,108,117,119 000001
999
CRANK , FROM CHASSIS: 000,002,010 046471 015 047683 100,102,110 111771 103,112 112413 115 051671 005,017,105,107,108,117,119 000001, Replaced By: A1237600102
999
INSERT LEFT
999
ESCUTCHEON LEFT
999
WASHER
999
WASHER , Replaced By: A1087680113
999
SLIDE , Replaced By: A1155860072
999
REPAIR KIT , Replaced By: A1145860172
999
REPAIR KIT CONVERSION OF REAR DOOR
999
GARNISH MOULDING LEFT
999
WELT , Replaced By: A1147300180
999
RETAINING RAIL
999
LOCKING EYE LEFT
999
PLATE 0.5 MM, FROM CHASSIS: 010 031987, ALSO INSTALLED ON: 026127-026384 110 071329, ALSO INSTALLED ON: 057116-057347
999
PLATE 1.5 MM, FROM CHASSIS: 010 031987, ALSO INSTALLED ON: 026127-026384 110 071329, ALSO INSTALLED ON: 057116-057347
999
WINDOW RUN 2275 MM LONG
999
SEAL , Replaced By: A1157280180
999
DOOR SHELL , Replaced By: A1157301105
999
PANELLING LEFT REAR DOOR
999
WINDOW STAYBAR LEFT
999
DOOR LOCK LEFT,LESS DOOR INNER LOCK
999
WINDOW REGULATOR RAIL LEFT, FROM CHASSIS: 015,115 200001 110 400001
999
PANELLING LEFT, STATE COLOR NUMBER WHEN ORDERING
999
DOOR LOCKING DEVICE LEFT
999
PANELLING RIGHT, STATE COLOR NUMBER WHEN ORDERING
999
PANELLING LEFT
999
DOOR SHELL LEFT
999
WEATHERSTRIP LEFT
999
EDGE GUARD SECTION LEFT, STATE COLOR NUMBER WHEN ORDERING NO LONGER INSTALLED ON 005,105,108
999
CRANK OPERATED WINDOW LEFT, DELIVER ADDITIONALLY:1X 115 730 05 45 UP TO CHASSIS: 015,115 200000 110 400000 010,112 UNTIL PRODUCTION STOP
999
PULL ROD LEFT, FROM CHASSIS: 000,002,010 083019 ALSO INSTALLED ON 055487-055613 015 096865 ALSO INSTALLED ON 059434-049645 FROM CHASSIS: 100,102,103,110,112 211691 ALSO INSTALLED ON 137775-138117 115 104055 ALSO INSTALLED ON 064365-064536
999
SEAL LEFT
999
GLASS PANE LEFT
999
SEAL LEFT
999
GARNISH MOULDING LEFT
999
DOOR HANDLE OUTSIDE LEFT
999
INTERIOR HANDLE ASSEMBLY LEFT, FROM CHASSIS: 010 083019, ALSO INSTALLED ON: 055487-055613 110 211691, ALSO INSTALLED ON: 137775-138117 017,117 000001
999
PAD , Replaced By: A1157660205
999
PAD LEFT
999
MOLDED PIECE , Replaced By: A0029888378
999
CLIP , 003030
999
WASHER , Replaced By: N000125004319
999
WASHER BRACKET TO SUPPORT
999
WASHER , UP TO CHASSIS: 017 029988 114 000523 117 064694
999
SCREW , UP TO CHASSIS: 017 029988 114 000523 117 064694
999
SCREW COVER PLATE TO BRACKET
999
SCREW , Replaced By: N304017006034
999
TOOTHED WASHER CABLE TO FUSE BOX
999
TOOTHED WASHER MASKED STOP LAMP
999
SHEET METAL SCREW ANTENNA CABLE TO REAR INSIDE PILLAR
999
SCREW
999
SCREW ,K 062140, Replaced By: N007985006580
999
SCREW APPARATUS PLATE TO CAB,K 062140
999
SCREW
999
SCREW
999
SCREW PUMP TO BRACKET
999
SCREW COVER PLATE TO COVER PLATE M 6 X 10
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
999
COMBINATION BOLT , Replaced By: A1239900317
999
SHEET METAL SCREW COVERING TO OUTSIDE CENTRAL PIECE
