Поз.
Артикул
Описание
3
REPAIR KIT FRONT SUBFRAME
3
REPAIR KIT , Replaced By: A1153301875
4
RUBBER BUFFER
5
RETAINER
6
RUBBER MOUNTING
7
NUT
8
U-BOLT
12
STOP
13
SCREW
14
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
25
BRACKET , Replaced By: A1074201186
28
TAPERED ROLLER BEARING INSIDE,F 023121 ALSO INSTALLED ON F 027127
29
SEAL RING
30
TAPERED ROLLER BEARING OUTSIDE,F 023121 ALSO INSTALLED ON F 027127
31
REPAIR KIT , Replaced By: A1153300051
31
REPAIR KIT FRONT WHEEL BEARING
32
RING
33
NUT
34
SCREW , ON SPECIAL REQUEST, FLOOR SHIFT
36
HUB CAP
37
CONTACT SPRING , Replaced By: A2015470085
37
CONTACT SPRING FRONT WHEEL HUB TO STEERING KNUCKLE
42
REPAIR KIT , Replaced By: A1153301775
42
REPAIR KIT UPPER TRANSVERSE CONTROL ARM
43
BEARING , NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIR KIT
48
REPAIR KIT LOWER CONTROL ARM
48
REPAIR KIT , Replaced By: A1153301675
49
REPAIR KIT , Replaced By: A0003330260, +001A0003330660, +001A0003330797, +001N913002014002
49
REPAIR KIT , Replaced By: A1143300185
49
DUST COLLAR LOWER CONTROL ARM JOINT BOOT
50
NUT PLATFORM MOUNTING
51
NUT AT CROSS MEMBER
62
BOOT , Replaced By: A0003300485
62
REPAIR KIT , Replaced By: A1143300085
62
REPAIR KIT TIE ROD BOOT AND DRAG LINK BOOT,RESP., 000,003,007,102,103,105,200 10/50,12/52 A 063106 20/60,22/62 A 072608 083,086,093,183,190,193,280,283 F 007678
63
NUT
64
NUT LOWER CONTROL ARM TO FRAME
65
SCREW , Replaced By: N000961012208
66
NUT FRONT SPRING FRONT BRACKET TO SIDE MEMBER
87
SCREW
87
REPAIR KIT , Replaced By: A1159901901, +001A1159902101, +001A1209900155, +001A1159940732, +001N202019130200, +001N204000007709, +001N204019130900, +001N401019130100, +001N402019130200, +001N802009130400
999
STEERING ARM RIGHT, 100835
999
INDEXING PLATE
999
PIN
999
BEARING
999
BRACKET , Replaced By: A1074201286
999
REPAIR KIT , Replaced By: A1155860433
999
REPAIR KIT , Replaced By: A1155860533
999
REPAIR KIT , Replaced By: A1159940732, +001A1209900155, +001N202019130200, +001N204000007709, +001N204019130900, +001N401019130100, +001N402019130200, +001N802009130400
999
LOCK
999
COTTER PIN CONNECTOR TO BRAKE PRESSURE REGULATOR LEVER
999
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
999
NUT BRACKET TO CROSS MEMBER
999
BOOT , Replaced By: A0003381397
999
CLAMPING RING BOTTOM, NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIR KIT
999
CLAMPING RING TOP, NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIR KIT
999
BOOT , NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIR KIT
999
NUT , Replaced By: N913004012008
999
NUT , Replaced By: N913001014001
999
TRANSVERSE CONTROL ARM BOTTOM RIGHT
999
STEERING KNUCKLE RIGHT
999
BRACKET LEFT
999
BRACKET RIGHT
999
HUB CAP , Replaced By: A1083340025, +002A2015470085
999
REPAIR KIT UPPER CONTROL ARM JOINT
999
STOP
999
TIE ROD , Replaced By: A1073300103, +002N913002010002
999
RUBBER MOUNTING , Replaced By: A1073300275
999
HALF FRONT AXLE LEFT, FROM CHASSIS: 000,002,010 094997 015 115510 100,102,103,110,112 244251 115 122220 005.017,105,107,108,117,119 000001
999
HALF FRONT AXLE RIGHT, FROM CHASSIS: 000,002,010 094997 015 115510 100,102,103,110,112 244251 115 122220 005.017,105,107,108,117,119 000001
999
TRANSVERSE CONTROL ARM , Replaced By: A1153303807
999
TRANSVERSE CONTROL ARM , Replaced By: A1153303907
999
TRANSVERSE CONTROL ARM , Replaced By: A1073301207
999
TRANSVERSE CONTROL ARM , Replaced By: A1073301307
999
TRANSVERSE CONTROL ARM , Replaced By: A1153303807
999
TRANSVERSE CONTROL ARM , Replaced By: A1153303907
999
TRANSVERSE CONTROL ARM , Replaced By: A1073301307
999
TRANSVERSE CONTROL ARM , Replaced By: A1153303807
999
TRANSVERSE CONTROL ARM , Replaced By: A1153303907
999
TRANSVERSE CONTROL ARM TOP RIGHT
999
DUST CAP , Replaced By: A1153300177
999
STEERING KNUCKLE , Replaced By: A1073320001
999
STEERING KNUCKLE , Replaced By: A1073320002
