Поз.
Артикул
Описание
137
COVER
224
CABLE HARNESS COLD START, 020 020327, ALSO INSTALLED ON: 020144,020269,020271,020273,020285,020287,020289,020294-020314,020316-020325.
226
PIN BUSHING HOUSING ELECTRIC CHANGE-OVER VALVE
227
CAP , Replaced By: A0125450428, +001A0125450528
227
COVERTO 008 545 08 28,008 545 09 28
228
VALVE , Replaced By: A0015408697
228
VALVE (3/2-WAY SOLENOID VALVE)
232
SHEET METAL SCREW BRACKET TO FLOOR PLATE
232
SHEET METAL SCREW ANTENNA CABLE TO REAR INSIDE PILLAR
232
SHEET METAL SCREW BRACKET TO FLOOR PLATE, Replaced By: N000000000460
238
FUSE BOX
238
FUSE BOX
240
GASKET
242
COVER
242
COVER
244
RUBBER PAD
244
RUBBER PAD
245
MARKING STRIP FUSE BOX
248
RUBBER BUFFER , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A1159870240
252
FLANGE
253
FUSEA16
253
FUSE25 A
253
FUSEA8
253
FUSE , Replaced By: N072581008101
253
FUSE FUSE BOX A 25
262
LOCK WASHER BRACKET TO STEERING COLUMN END
263
SHEET METAL SCREW BRACKET TO CAB FLOOR
267
PIN BUSHING HOUSING ELECTRIC CHANGE-OVER VALVE
268
COVERTO 008 545 08 28,008 545 09 28
268
CAP , Replaced By: A0125450428, +001A0125450528
269
ROUND PIN BUSHING4 MM2
270
PLUG CHASSIS/CAB PLUG CONNECTION
271
PLUG HOUSING
271
PLUG , Replaced By: A0065457828, +006A0015453826, +001A0095453028
273
CLAMP ELECTRIC CABLE TO BRACKET
281
PLUG , Replaced By: A0009871840
281
RUBBER BUFFER TO PLUG THE MOUNTING HOLE USED FOR GROUND CONNECTION IN CASE OF R.H.D.
282
GROMMET ENGINE COMPARTMENT LAMP
282
GROMMET FOR PASSAGE OF LINE, UP TO IDENT NO. 5 033766,ALSO INSTALLED ON 5 039977
282
GROMMET
283
BOOT HEATER PLUGS
284
CABLE CONNECTOR , FROM CHASSIS:108.016 050831 108.018 053598 108.019 054235
286
SHEET METAL SCREW CABLE CONNECTOR TO RIGHT WHEEL ARCH PANEL
288
SCREW STEERING COLUMN MOUNTED SWITCH TO STEERING COLUMN BRACKET M4X10
288
SCREW , Replaced By: N007985004107
290
LOCK WASHER CABLES TO CABLE CONNECTOR
291
CABLE SHOE
296
SHEET METAL SCREW CABLE CONNECTOR TO RIGHT WHEEL ARCH PANEL
298
SCREW STEERING COLUMN MOUNTED SWITCH TO STEERING COLUMN BRACKET M4X10
298
SCREW , Replaced By: N007985004107
300
LOCK WASHER T-FITTING TO BRACKET
302
SCREW BATTERY CABLE MOUNTING AND MAIN CABLE HARNESS MOUNTING
302
SCREW , Replaced By: N007985005157
304
LOCK WASHER BRACKET TO STEERING COLUMN END
306
SCREW REGULATOR AND CUT-OUT M 6X12
308
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
309
SCREW PUMP TO BRACKET
309
SCREW COVER PLATE TO BRACKET
999
CONNECTION PLATE
999
PLUG
999
CABLE SHOE CABLE HARNESS FOR ELECTRIC SEAT ADJUSTER
999
BATTERY ACID BOTTLE SET , Replaced By: A0009891315
999
BATTERY ACID BOTTLE SETTO 001 541 79 01
999
VALVE , Replaced By: A0015407097, +002A1170780981
999
VALVE , Replaced By: A0015406897, +001A1170780981
999
PLUG PIN ADDITIONAL CABLE TO SERIES CABLE
999
CLAMP ELECTRIC CABLE MOUNTING
999
LOOM TIE , UP TO CHASSIS: 108.012 UNTIL PRODUCTION STOP 108.016 042417 108.018,019 043374 109.016 002452
999
LOOM TIE , Replaced By: A0019974390
999
LOOM TIE TO MOUNT PLASTIC PIPING
999
BATTERY , Replaced By: A0035416601
999
PLUG , Replaced By: A0095455428, +012A0015453826, +001A0095452428
999
PLUG , Replaced By: A0095452628, +012A0035452626, +001A0095452428
999
PLUG , Replaced By: A0085453728, +002A0035452626, +001A0085453828
999
BATTERY PARTS KIT,5 338284
999
PART NAME MISSING. PLUG , Replaced By: A0125450328, +014A0015453826, +001A0095455728
999
PLUG , Replaced By: A0105450428, +015A0015452826, +001A0105450528
999
PLUG , Replaced By: A0085450828, +002A0015454426, +001A0085451128
999
PLUG
999
PLUG , Replaced By: A0075450028, +004A0035452626, +001A0095452128
999
PLUG , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0065458028, +006A0015453726, +001A0095453028
999
PLUG , Replaced By: A0095459928, +008A0015452826, +001A0095459828
999
PLUG , Replaced By: A0095454228, +004A0035452626, +001A0095454328
999
PLUG , Replaced By: A0085450828, +002A0015454426, +001A0085451128
999
SHELL , Replaced By: A1075450530, +001A2015400183
999
SHELL , 003 112822 007 103309 086 007452 093 010619 102,103 339978 105 280994 183 019384 190 024567 193 007304 200 107838 280 003324 283 008567
999
LOOM TIE
999
LOOM TIE , Replaced By: A1149970590
999
LOOM TIE
999
SCREW
999
SCREW TAIL LAMP GROUND CABLE TO WHEEL ARCH PANEL
999
NUT BOOT TO AIR DUCT AND TO AIR CLEANER
999
SHEET METAL SCREW , Replaced By: N000000002062
999
WASHER , Replaced By: N009021005205
999
WASHER CABLE CONNECTOR TO BRACKET AND TO FRAME,RESP.
