Поз.
Артикул
Описание
5
CONTROL UNITTEMPOMAT
5
CONTROL UNITTEMPOMAT
8
SHEET METAL SCREW CONTROL UNIT TO BRACKET
8
SHEET METAL SCREW FUEL STRAINER SCREEN TO FUEL TANK
8
SHEET METAL SCREW BRACKET TO CAB FLOOR
8
SHEET METAL SCREW , Replaced By: N000000000459
8
SHEET METAL SCREW , Replaced By: N007981004339
14
BRACKET CONTROL UNIT
14
BRACKET
20
SCREW CAB FLOOR COVERING M 6X25
23
NUT CYLINDER TO BRACKET TO0002902112
23
NUT BATTERY MOUNTING
26
SPRING WASHER LICENSE PLATE TO BRACKET
29
SHEET METAL SCREW , Replaced By: N000000002062
29
SCREW
32
CONTROL UNIT ACTUATOR
35
BRACKET AT WHEEL ARCH
38
NUT BATTERY MOUNTING
38
NUT CYLINDER TO BRACKET TO0002902112
41
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
44
NUT
45
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
45
SPRING WASHER , Replaced By: N000137008212
47
LOCK FOR BOWDEN CABLE CLIP
50
WIRE CABLE
53
SHEET METAL SCREW MODULE TO HOUSING
53
SHEET METAL SCREW , Replaced By: N000000000453
59
CLAMP WIRE CABLE TO FIRE WALL
62
COMBINATION BOLT WIRE CABLE TO FIRE WALL
65
HOSE
71
HOSE1150 MM, ORDER BY THE METER
77
HOSE AERATION 900 MM
83
BRANCH-OFF FITTING
86
HOSE *** 30 MM
89
NUT
999
CABLE HARNESS , 107.042 L.H.D. A 005251 107.042 R.H.D. A 007244 123. L.H.D. A 154543,F 018236 123. R.H.D. A 118486,F 020925, Replaced By: A1235409608, +001A0015426119
999
CABLE HARNESS , 107.042 L.H.D. A 005251 107.042 R.H.D. A 007244 123. L.H.D. A 154543,F 018236 123. R.H.D. A 118486,F 020925, Replaced By: A1235409508, +001A0015426119
