124.020 200-300 9/89-10/92, 200D-300D 9/89-7/93
32 SPRINGS,SUSPENSION AND HYDRAULICS
001 HYDRAULIC SYSTEM USED WITH AUTOMATIC LOCKING DIFFERENTIAL (ASD) (FOR TYPE R129,W IL.3

Mercedes N304017006018 - Болт

200 124.020 200-300 9/89-10/92, 200D-300D 9/89-7/93

32 SPRINGS,SUSPENSION AND HYDRAULICS - 001 HYDRAULIC SYSTEM USED WITH AUTOMATIC LOCKING DIFFERENTIAL (ASD) (FOR TYPE R129,W IL.3

Поз.
Артикул
Описание
5
A1246200272
STIFFENING FRONT CENTRAL
8
A1246203786
SUPPORT RADIATOR SUPPORT, ORDER ADDITIONALLY FOR USE WITH HIGH-MOUNTED RADIATOR: 2 X 124 620 19 31
11
A1246260530
COVERING RADIATOR SUPPORT
14
A1246260916
REINFORCEMENT IN FRONT OF LOW-MOUNTED RADIATOR
17
A1246262231
CONSOLE RADIATOR SUPPORT, USED WITH LOW-MOUNTED RADIATOR
23
A1246260031
CONSOLE RADIATOR SUPPORT, USED WITH HIGH-MOUNTED RADIATOR
26
A1246201931
CONSOLE (ADAPTER),RADIATOR MOUNTING, USED WITH HIGH-MOUNTED RADIATOR
35
A1246202614
BRACKET RIGHT RADIATOR MOUNTING CONSOLE
35
A1246202714
BRACKET LEFT RADIATOR MOUNTING CONSOLE
38
N914007006012
COMBINATION BOLT , Replaced By: N304017006018, +001N006902006102
38
N304017006018
SCREW COVER PLATE TO COVER PLATE M 6 X 12
41
N913017006000
NUT , Replaced By: N910112006001
44
A1246202985
STRUT BETWEEN FRONT CROSS MEMBER AND FRONT CENTRAL STIFFENING,F 096580
47
N910105006002
HEXAGON HEAD BOLT
