200 CE / E 200
124.060 FROM 09/89
46 STEERING
090 STEERING COLUMN JACKET TUBE AND STEERING SHAFT,ELECTRICALLY ADJUSTABLE IL. 1

Mercedes N304017006018 - Болт

200 CE / E 200 124.060 FROM 09/89

46 STEERING - 090 STEERING COLUMN JACKET TUBE AND STEERING SHAFT,ELECTRICALLY ADJUSTABLE IL. 1

Поз.
Артикул
Описание
68
A1248600305
AIRBAG UNIT , FROM CHASSIS NEW EQUIPMENT 9/89 UP TO CHASSIS NEW EQUIPMENT 7/93 NO.9045I NO.5070I NO.8310I NO.8320I NO.8411I NO.6121I NO.3111I NO.7095I
68
A1248600405
AIRBAG UNIT , FROM CHASSIS NEW EQUIPMENT 7/93NO.9045I NO.5070I NO.8310I NO.8F19I NO.8F33I NO.6121I NO.3111I NO.7095I I
71
A1269900215
SCREW
74
A1246800916
REINFORCEMENT
77
A1246800514
BRACKET INSTRUMENT PANEL,LEFT
80
A1246800414
BRACKET INSTRUMENT PANEL,RIGHT
83
A1246800111
PLATE
86
A1246892314
BRACKET
86
A1246285714
BRACKET
89
A1246892414
BRACKET
92
N914112006009
SCREW
95
N304017006018
SCREW COVER PLATE TO COVER PLATE M 6 X 12
98
N009021006208
WASHER COMPRESSED AIR LINE TO BRACKET
101
N914116006412
SCREW
107
A1249900422
SCREW
