Поз.
Артикул
Описание
5
TANK
11
SEAL VACUUM SUPPLY TANK
26
FOAM PLASTICS FRONT ROOF RAIL
29
NUT
29
NUT , Replaced By: N304032008006
32
RIVET , Replaced By: A0009904292
32
RIVET , Replaced By: A0009904892
32
RIVET
101
ELEMENT CO-DRIVER'S DOOR, 000 195485 003 105699 007 090655 086 007259 093 009523 102,103 254516 105 240288 183 016292 190 022605 193 003387 200 039776 280 001513 283 005421
101
ELEMENT CO-DRIVER'S DOOR
101
ELEMENT CO-DRIVER'S DOOR, 123.053 024919 153 000547 243 011304
104
COVERINGTO 123 800 33 75
107
CONTROL ROD LEFT
107
CONTROL ROD RIGHT
107
CONTROL ROD RIGHT
107
CONTROL ROD LEFT
110
LOCK PLATE , 000 000032 003 000013 007 000799 086 006409 093 007546 102,103 000031 105 000017 183 013075 190 019713 283 001214
116
SHEET METAL SCREW SEAT HEATER CONTROL TO CROSS MEMBER AND TO FRONT SEAT
122
CLIP
125
CLIP
125
CLIP , Replaced By: A0069886378
128
ELEMENT REAR LID
143
SHEET METAL SCREW SEAT HEATER CONTROL TO CROSS MEMBER AND TO FRONT SEAT
158
ELEMENT FUEL FILLER NECK
158
ELEMENT FUEL FILLER NECK, UP TO CHASSIS: 123.053 02120850 006732 243 002230
170
WASHER , Replaced By: N000125004319
170
WASHER BRACKET TO SUPPORT
173
SPRING
176
BUSHING , 000 194867 003 101568 007 085543 102,103 232424 105 226121 200 021073
176
BUSHING
182
HOSE ORDER BY THE METER
191
HOSE *** 30 MM
197
CLIP CABLE HARNESS TO ROOF RAIL
203
GROMMET COMBINED TAIL LAMP CABLE HARNESS THRU REAR PANEL
206
RUBBER RING
209
LOOM TIE TO MOUNT PLASTIC PIPING
209
LOOM TIE , UP TO CHASSIS: 108.012 UNTIL PRODUCTION STOP 108.016 042417 108.018,019 043374 109.016 002452
209
LOOM TIE
209
LOOM TIE
209
LOOM TIE
209
LOOM TIE , Replaced By: A0019974390
209
LOOM TIE
209
LOOM TIE , Replaced By: A1149970590
999
ADHESIVE TAPE *** 4X9X45 MM, ORDER BY THE METER
