Поз.
Артикул
Описание
32
EXHAUST MUFFLER WITH PIPE CENTRAL
65
CLAMP
68
SCREW VALVE TO BRACKET M 8X55
68
SCREW , Replaced By: N304017008043
69
WASHER BRACKET TO CROSS MEMBER
70
NUT FROM CONTROL LEVER TO INTERMEDIATE SHAFT AT ENGINE
80
HEXAGON HEAD BOLT. SCREW CLUTCH TO FLYWHEEL
80
SCREW , Replaced By: N304017008053
83
SCREW VALVE TO BRACKET
89
NUT POWER CYLINDER TO BRACKET
89
NUT , Replaced By: A0009903250
92
SEAL RING , Replaced By: A2024920181
92
SEAL RING FRONT EXHAUST PIPE TO CENTRAL EXHAUST PIPE E36 AMG
122
DISC SPRING FRONT EXHAUST PIPE TO BRACKET, FROM IDENT NO. 941506 ALSO INSTALLED ON 899081-941503 ONLY WITH OM601/OM602 ENGINEP 000001P 050586
125
WASHER HIGH PRESSURE HOSE TO BRACKET
128
SCREW PIPE CLAMP
128
SCREW , Replaced By: N304017008021
131
RUBBER RING BRACKET TO MOUNTING PLATE OR TO TRANSMISSION
134
NUT BRACKET TO MOUNTING PLATE OR TO TRANSMISSION
143
SUSPENSION RING MAIN MUFFLER SUSPENSION
146
CLAMPING PIECE MAIN MUFFLER SUSPENSION
149
COMBINATION BOLT BRACKET TO EXHAUST MUFFLER
152
WASHER , Replaced By: N000125008443
155
DAMPING PAD EXHAUST PIPE SUSPENSION
