Mercedes
CAR
300 TD TURBODIESEL 4 MATIC
124.393 200-300 9/89-10/92, 200D-300D 9/89-7/93
46 STEERING
090 STEERING COLUMN JACKET TUBE AND STEERING SHAFT,ELECTRICALLY ADJUSTABLE IL. 1

Mercedes N304017006018 - Болт

300 TD TURBODIESEL 4 MATIC 124.393 200-300 9/89-10/92, 200D-300D 9/89-7/93

46 STEERING - 090 STEERING COLUMN JACKET TUBE AND STEERING SHAFT,ELECTRICALLY ADJUSTABLE IL. 1

Поз.
Артикул
Описание
5
A1246200272
STIFFENING FRONT CENTRAL
8
A1246203786
SUPPORT RADIATOR SUPPORT, ORDER ADDITIONALLY FOR USE WITH HIGH-MOUNTED RADIATOR: 2 X 124 620 19 31
11
A1246260530
COVERING RADIATOR SUPPORT
14
A1246260916
REINFORCEMENT IN FRONT OF LOW-MOUNTED RADIATOR
17
A1246262231
CONSOLE RADIATOR SUPPORT, USED WITH LOW-MOUNTED RADIATOR
20
A1246260031
CONSOLE RADIATOR SUPPORT, USED WITH HIGH-MOUNTED RADIATOR
23
A1246201931
CONSOLE (ADAPTER),RADIATOR MOUNTING, USED WITH HIGH-MOUNTED RADIATOR
25
A1246202614
BRACKET RIGHT RADIATOR MOUNTING CONSOLE
25
A1246202714
BRACKET LEFT RADIATOR MOUNTING CONSOLE
26
N304017006018
SCREW COVER PLATE TO COVER PLATE M 6 X 12
27
A1246203285
STRUT BETWEEN FRONT CROSS MEMBER AND FRONT CENTRAL STIFFENING
29
N910105006002
HEXAGON HEAD BOLT
