Поз.
Артикул
Описание
5
HOSE TOP
14
HOSE BOTTOM
32
LOOM TIE. CLAMP HOSE FASTENING
32
CLAMP , Replaced By: A0069974390
38
CLAMP , Replaced By: A0069970690
41
HOSE FROM EXPANSION TANK TO RADIATOR, 032,033 049244 036,037 037286 TO BE INSTALLED ONLY FOR USE WITH SECOND ALTERNATOR
41
HOSE , 032,033 049244 036,037 037286 TO BE INSTALLED ONLY FOR USE WITH SECOND ALTERNATOR, Replaced By: A1265001175
56
HOSE , Replaced By: N000000000734
56
HOSE ENGINE BREATHING 8X15X2550MM, TO BE ADAPTED DURING ASSEMBLY
65
CLAMP25-40X13 MM
65
CLAMP , Replaced By: A0069970490
66
CLAMP PRESSURE REGULATOR
66
LOOM TIE HOSE TO RADIATOR AND TO EXPANSION TANK
68
HOSE CLAMP LINE MOUNTING
68
CLAMP , Replaced By: A0059970190
68
CLAMP , Replaced By: A1409950036
74
BRACKET , Replaced By: A1265010220
74
BRACKET RIGHT FRONT
77
BRACKET JACK FIXTURE
80
CLAMP , UP TO CHASSIS107.024 012078 107.044 029875
83
SCREW
83
SCREW , Replaced By: A1269901036
83
SCREW , Replaced By: A2039900036
89
TANK EXPANSION TANK
92
RADIATOR CAP
95
COVER PARTS KIT TO 1245000649, A 136172 F 025324
101
SWITCH COOLING WATER LEVEL INDICATOR
104
SEAL RING
107
LOCK RING MAIN SHAFT,FRONT
110
HOSE
110
HOSE , Replaced By: A0219977682
113
BRACKET EXPANSION TANK TO WHEELHOUSE
116
COMBINATION BOLT. TAPPING SCREW , Replaced By: N000000000548
116
TAPPING SCREW PROTECTIVE GRILLE 4.8X16 MM
122
TANK OVERFLOW,A 416329
122
TANK , Replaced By: A1265000549, +001A1264300310, +003N000933004067, +003N000934004006, +003N009021004108
122
TANK OVERFLOW, ONLY FOR USE WITH AIR CONDITIONER,OR WITH AIR CONDITIONING AUTOMATICS
125
BRACKET
125
BRACKET ,A 416329
128
SCREW AT INSTRUMENT PANEL M 4X16,036897
131
WASHER , Replaced By: N009021004207
131
WASHER COVERING TO CYCLONE AIR TRAP
134
NUT BOOT TO AIR DUCT AND TO AIR CLEANER
137
SHEET METAL SCREW BRACKET TO CAB FLOOR, EXHAUST STOCK OF OLD PARTS NUMBER FIRST UP TO CHASSIS 5 180559
140
NUT , Replaced By: N913002006009
143
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
146
HOSE FROM FEED LINE TO FILTER 240 MM
146
HOSE DE-AERATION B8X12,5 218304 ORDER BY THE METER
149
GROMMET BATTERY CASE
152
EDGE GUARD SECTION , Replaced By: A0029873572
