Поз.
Артикул
Описание
480
BRACKET ENGINE
496
GEARING ELECTRIC SLIDING ROOF, 033 102015 123 329277 130 276372
502
CLIP
508
GROMMET GEARING TO BRACKET
514
BUSHING MOTOR TO BRACKET
520
SCREW COVER PLATE TO BRACKET
526
NUT BALL PIVOT TO LEVER
538
CONNECTOR
552
ELECTRIC MOTOR
558
PLUG HOUSING
564
CLIP PLUG TO REAR PILLAR
568
GROMMET GEARING TO BRACKET
572
BUSHING MOTOR TO BRACKET
576
SCREW COVER PLATE TO BRACKET
582
HEXAGON HEAD BOLT
586
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
590
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
594
LOCK BRACKET WITH MOTOR AND GEARING TO REAR PILLAR, 033 102015 123 329277 130 276372 133 008386 223 100392
598
WASHER COVER PLATE TO COVER PLATE
602
SHEET METAL SCREW , NOT USED
603
NUT RETAINER DRIVE TO REAR PILLAR
604
HEXAGON HEAD BOLT
605
RUBBER BUFFER REAR
606
TUBE SLIDING ROOF
606
TUBE SLIDING ROOF, 026 112096 033 102016 120 314854 123 329278 130 276373 133 008387 220 085658 223 100393
606
TUBE FROM REINFORCEMENT FRAME CENTER TO WORM GEARING IN LUGGAGE COMPARTMENT
609
CABLE SLIDING ROOF
609
CABLE
610
BRACKET
611
SHEET METAL SCREW ALARM UNIT TO STRUT
624
CLAMP TUBE TO REAR PILLAR
630
SHEET METAL SCREW BRACKET TO CAB FLOOR
630
SHEET METAL SCREW ALARM UNIT TO STRUT
999
LOCK. PIN LOCK ORNAMENTAL COVER TO BUMPER
999
STAY
