Поз.
Артикул
Описание
38
PARKING BRAKE
38
PARKING BRAKE , Replaced By: A1264200684
41
PAWL , Replaced By: A1264270315
41
PAWL
44
LOCK PLATE RELEASE LEVER TO SHAFT
47
WASHER , Replaced By: N000125010532
50
ROD
53
PIN
56
COTTER PIN BRACKET TO BATTERY CASE, 415 5 014668 416 5 000515 417 4 972023
59
LEVER
62
PIN
65
COTTER PIN BRACKET TO BATTERY CASE, 415 5 014668 416 5 000515 417 4 972023
68
BALL SOCKET PULL ROD TO INTERMEDIATE LEVER
71
CIRCLIP. SECURING CLIP BALL SOCKET TO ROD
74
ROD
77
NUT BALL PIVOT TO LEVER
80
CLAMPING SPRING
83
CONNECTOR
86
PIN
89
COTTER PIN LEVER TO ROD, Replaced By: N000094002060
92
SPRING
92
SPRING
95
SPRING
98
HANDLE , 000 093251 003 046617 102,103 073879 105 093170
101
SPACER TUBE
104
DAMPING RING
107
GUIDE
110
SCREW
113
TOOTHED WASHER , 123.020 082784 123.023 100522 123.026 050534 123.120 116041 123.123 080963 123.126 045537 123.130 101733
116
NUT TACHOGRAPH TO BRACKET
119
SPRING
122
HOSE30 MM, ORDER BY THE METER
125
NUT CLAMP TO BRACKET
125
NUT , Replaced By: N913019006000
125
NUT , Replaced By: N913012006001
128
NUT RETAINER ,123 415950
131
SCREW COVER PLATE TO BRACKET
134
SPRING WASHER LICENSE PLATE TO BRACKET
137
WASHER INSTRUMENT PANEL TO BRACKET
140
SCREW HANDLE TO RATCHET ROD
143
WASHER REFLECTOR TO BRACKET
146
LOOM TIE LINE MOUNTING 150 X 3,6 MM
146
LOOM TIE LINE MOUNTING 280 MM
152
BRAKE CABLE FRONT, A 417163
152
BRAKE CABLE FRONT
161
CLAMP , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A1089950520
161
CLAMP FORKED SUPPORT,TOP
164
SHEET METAL SCREW VALVE TO WINDOW SILL
167
SPRING
170
SPACER TUBE BRAKE CABLE TO REAR FLOOR
173
SHACKLE
176
SCREW , Replaced By: N304017008027
179
PIN BRAKE CABLE TO INTERMEDIATE LEVER
182
COTTER PIN ROLLER TO LEVER
185
SPRING
188
BRAKE CABLE REAR LEFT
191
BRAKE CABLE REAR RIGHT
194
SCREW , Replaced By: N000933010162
194
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
197
COMBINATION BOLT BRAKE CABLE TO REAR AXLE
200
SPRING WASHER SHIFTING ROD TO BRACKET
203
GROMMET BRAKE CABLE TO REAR AXLE
206
SPRING
