Поз.
Артикул
Описание
17
LEVER ACCELERATOR PEDAL
26
BEARING
32
SHIM BEARING TO FIRE WALL
38
BOOT BEARING TO FIRE WALL
41
SHEET METAL SCREW RIGHT TOP ANTINOISE CAPSULE TO CAB B 6.3X25
44
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
47
TAPPING SCREW PROTECTIVE GRILLE 4.8X16 MM
47
COMBINATION BOLT. TAPPING SCREW , Replaced By: N000000000548
50
GASKET BEARING TO FIRE WALL
53
SPACER RING
56
BRACKET
59
LOCK
59
LOCK , Replaced By: A0019946045
59
LOCK , Replaced By: A0029945545
86
SPRING ACCELERATOR PEDAL RESET, FROM IDENT NO. 941506, P 000001 ALSO INSTALLED ON 899081-941503 ONLY WITH OM601/OM602 ENGINE
92
LEVER
95
BEARING BRACKET
98
SHEET METAL SCREW BRACKET TO CAB FLOOR
101
WASHER BRACKET TO SUPPORT
101
WASHER , Replaced By: N000125004319
104
LOCK PLATE RELEASE LEVER TO SHAFT
107
FITTED WASHER
125
SHAFT
125
SHAFT
131
LEVER
131
LEVER (CONTROL LEVER)
140
SCREW , Replaced By: N304017006018
143
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
248
ROD FROM ACCELERATOR PEDAL TO INTERMEDIATE LEVER
248
ROD , Replaced By: A1263000915
248
ROD
254
ROD FROM INTERMEDIATE LEVER TO ENGINE CONTROL SHAFT
257
NUT TACHOGRAPH TO BRACKET
260
BALL SOCKETTO 102 070 09 75, Replaced By: A0009930461
260
BALL SOCKET , Replaced By: A0009918922
263
RUBBER BUFFER
266
BUSHING
290
GROMMET
293
BOOT FROM CLUTCH MASTER CYLINDER LINE TO SLAVE CYLINDER
299
SWITCH , NOT USED
299
SWITCH , NOT USED
299
SWITCH (KICK-DOWN SWITCH)
