Поз.
Артикул
Описание
5
DOOR SHELL STEEL,WITH HOLES FOR TYPE DESIGNATION
8
SEAL REAR PANEL DOOR
11
HINGE LEFT
11
HINGE RIGHT
14
MOUNTING LEFT
14
MOUNTING RIGHT
17
PIN
20
SCREW
23
SCREW
26
EXPANSION PLUG PAINT RUN-OFF IN FLOOR,LATERAL
29
SPRING BETWEEN REAR PANEL DOOR AND REAR PILLAR
32
SCREW SPRING TO JOINT CONNECTION, 083 000189 086 000089 093 000063 183 000202 190 000189
35
SEAL RING SPRING TO JOINT CONNECTION, 083 000189 086 000089 093 000063 183 000202 190 000189
38
PIN SPRING TO HINGE
41
LOCK HOSE FASTENING
44
STRUT BETWEEN INTERIOR PART AND REAR PANEL DOOR PANELLING
47
SHEET METAL SCREW BRACKET TO CAB FLOOR
50
STOP LEFT REAR PANEL DOOR INTERIOR PART
50
STOP RIGHT REAR PANEL DOOR INTERIOR PART
53
PAD
56
SCREW BRACKET TO TAIL LAMP BRACKET
59
STOP LEFT REAR PILLAR
59
STOP RIGHT REAR PILLAR
62
PLATE REAR END PILLAR
65
SCREW , Replaced By: N000000001145
68
PLATE LEFT
68
PLATE RIGHT
