Поз.
Артикул
Описание
10
BACKREST FRAME LEFT
20
BACKREST FRAME RIGHT
30
LINING LEFT REAR BACKREST, 9F08QFT204A2500 SINGLE TONE BLACK
40
LINING RIGHT REAR BACKREST, 9F08QFT204A2500 SINGLE TONE BLACK
50
PAD REAR SEAT BACKREST LEFT
50
REST LEFT, FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. F 12295120110328, Replaced By: A2079202500
60
REST RIGHT, FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. F 12295120110328, Replaced By: A2079202600
60
PAD REAR SEAT BACKREST RIGHT
70
COVER REAR SEAT BACKREST LEFT
70
COVER LEFT
70
COVER LEFT
70
COVER REAR SEAT BACKREST LEFT
70
COVER REAR SEAT BACKREST LEFT
70
COVER LEFT
70
COVER LEFT
70
COVER REAR SEAT BACKREST LEFT
70
COVER REAR SEAT BACKREST LEFT
70
COVER LEFT
70
COVER LEFT
70
COVER REAR SEAT BACKREST LEFT
70
COVER REAR SEAT BACKREST LEFT, 8R01 874A QFT207A2093 ESPRESSO BROWN
70
COVER REAR SEAT BACKREST LEFT
70
COVER LEFT
70
COVER REAR SEAT BACKREST LEFT, 8S73 274A QFT207A2220 ESPRESSO BROWN
70
COVER LEFT
70
COVER LEFT
70
COVER REAR SEAT BACKREST LEFT
70
COVER REAR SEAT BACKREST LEFT
80
COVER RIGHT
80
COVER REAR SEAT BACKREST RIGHT
80
COVER RIGHT
80
COVER REAR SEAT BACKREST RIGHT
80
COVER REAR SEAT BACKREST RIGHT
80
COVER REAR SEAT BACKREST RIGHT, 8R01 874A QFT207A2093 ESPRESSO BROWN
80
COVER RIGHT
80
COVER RIGHT
80
COVER RIGHT
80
COVER RIGHT
80
COVER REAR SEAT BACKREST RIGHT
80
COVER REAR SEAT BACKREST RIGHT, 8S73 274A QFT207A2220 ESPRESSO BROWN
80
COVER RIGHT
80
COVER REAR SEAT BACKREST RIGHT
80
COVER REAR SEAT BACKREST RIGHT
80
COVER RIGHT
80
COVER REAR SEAT BACKREST RIGHT
80
COVER RIGHT
80
COVER REAR SEAT BACKREST RIGHT
80
COVER RIGHT
85
PLATE DESIGNO, 7K71QFT204A2185 CHROME
90
GUIDE SIGN DESIGNO
100
BRACKET
110
LOCK PLATE BRACKET MOUNTING
130
BACKREST OUTSIDE LEFT
130
BACKREST REAR SEAT BENCH,LEFT
130
BACKREST OUTSIDE LEFT
130
REAR SEAT BACKREST OUTSIDE LEFT
130
BACKREST OUTSIDE LEFT
130
BACKREST REAR SEAT BENCH,LEFT
130
BACKREST REAR SEAT BENCH,LEFT
130
REAR SEAT BACKREST OUTSIDE LEFT
130
BACKREST OUTSIDE LEFT
130
BACKREST OUTSIDE LEFT
140
REAR SEAT BACKREST OUTSIDE RIGHT
140
BACKREST REAR SEAT BENCH,RIGHT
140
BACKREST REAR SEAT BENCH,RIGHT
140
REAR SEAT BACKREST OUTSIDE RIGHT
140
BACKREST OUTSIDE RIGHT
140
REAR SEAT BACKREST OUTSIDE RIGHT
140
BACKREST REAR SEAT BENCH,RIGHT
140
BACKREST OUTSIDE RIGHT
140
BACKREST OUTSIDE RIGHT
140
BACKREST OUTSIDE RIGHT
150
MOUNTING CLIP BACKREST TO WHEEL ARCH AT RIGHT
170
HEXALOBULAR BOLT TIME-LAG RELAY M5X12
200
HEXAGON HEAD BOLT. SCREW BRACKET TO SIDE MEMBER M10X25
230
BEARING OUTSIDE LEFT
240
BEARING OUTSIDE RIGHT
250
SWITCH BACKREST LOCKING MECHANISM,RIGHT
260
RIVET SWITCH TO BEARING AT RIGHT
270
PIVOT PIN BEARING TO BACKREST FRAME AT LEFT
270
PIN TO BACKREST FRAME, LEFT
280
BEARING CENTRAL
290
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
300
HEXALOBULAR BOLT TIME-LAG RELAY M5X12
310
HEXAGON HEAD BOLT. SCREW BRACKET TO SIDE MEMBER M10X25
350
LOCK FOR SEAT BACKREST LEFT REAR BACKREST
350
UNLOCKING RIGHT REAR BACKREST
360
LEVER RELEASE HANDLE, RIGHT, 9051QFT204A2420 BLACK
360
LEVER LEFT RELEASE HANDLE, 9051QFT204A2420 BLACK
370
HEXALOBULAR BOLT AIR CLEANER TO BRACKET
400
BRACKET SEAT COVER MOUNTING,LONGITUDINAL, USED WITH LEATHER TRIM
410
BRACKET SEAT COVER MOUNTING,LONGITUDINAL, USED WITH LEATHER TRIM
420
CLIP
430
CLIP
450
COVER LEFT
460
BEAM LEFT
470
REINFORCEMENT LEFT
500
COVER LEFT
510
BEAM RIGHT
520
REINFORCEMENT RIGHT
900
CLUTCH ILLUMINATION AIR NOZZLE, RIGHT 2-PIN MQS,E10/3
910
CLUTCH RIGHT REAR SEAT BACKREST LOCK SWITCH 3-PIN MQS,S54/8
