Mercedes A2025010220 - Клипса

CLK 200 KOMPRESSOR 208.344

50 RADIATOR - 165 EXPANSION TANK,MOUNTING AND HOSES

Поз.
Артикул
Описание
5
A2025016382
HOSE TOP
8
A0069970590
LOOM TIE
8
N916026036000
CLAMP , Replaced By: A0069970590
11
A2025017682
HOSE BOTTOM
14
A0069974390
LOOM TIE. CLAMP HOSE FASTENING
14
A0069970690
LOOM TIE. CLAMP BRAKE HOSE 45-55 MM, DISCONTINUED,PART IS NO LONGER REQUIRED
20
A2025017382
HOSE
23
A0069970390
LOOM TIE HOSE TO RADIATOR AND TO EXPANSION TANK
23
A0069974290
CLAMP HOSE FASTENING 28-35 MM,V 207570
26
A2025000649
TANK EXPANSION TANK
32
A2105450024
SWITCH,AUTOMATIC EXPANSION TANK, A 328811 EXCEPT CODE 806 ALSO INSTALLED IN VEHICLE TO A 328810 WITH CODE 807
35
A0229972682
HOSE OVERFLOW 530 MM, ORDER BY THE METER
38
N000000000734
HOSE ENGINE BREATHING 8X15X2550MM, TO BE ADAPTED DURING ASSEMBLY
41
A0059970290
HOSE CLAMP8-16
47
A0019905850
NUT EXPANSION TANK TO WHEELHOUSE
50
A2015040112
RUBBER MOUNTING EXPANSION TANK TO WHEELHOUSE
53
A2025010120
BRACKET BREATHER LINE
59
A2025010220
BRACKET BREATHER LINE
