Поз.
Артикул
Описание
10
SLIDING ROOF FRAME
50
END STOP LEFT AND RIGHT SLIDING ROOF
250
SLOTTED SLIDE VALVE LEFT AND RIGHT PARTS KIT
400
TS HEX. HEAD TAPPING SCRE DELIVERY QUANTITY12 PCS., THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0179906301
400
BOLT FRAME TO ROOF
430
GEARED MOTOR
440
TS SCREW W HXL. SOCKET DELIVERY QUANTITY3 PCS.
450
ELECTRICAL WIRING HARNESS SLIDING ROOF
470
AIR DEFLECTOR
480
BEARING F WIND DEFLECTOR LEFT AND RIGHT PARTS KIT
500
RAIN CHANNEL
600
HOSE LINE FRONT RIGHT
610
EXPANSION PLUG SIDE MEMBER,TOP 45 MM
620
HOSE ASSEMBLY WATER DRAIN AT FRONT LEFT
620
HOSE WATER DRAIN AT FRONT LEFT, PART IS INCLUDED IN SIDEWALL PACKAGE CONTENTS (DG 63)
630
CLAMP
650
HOSE LINE AT SLIDING ROOF, FRONT
700
HOSE LINE LEFT REAR SLIDING ROOF
700
HOSE ASSEMBLY RIGHT REAR SLIDING ROOF
710
WATER DRAIN GROMMET HOSE LINE THROUGH RIGHT WHEEL WELL
720
BRACKET FUEL TANK BREATHING
730
LINE HOLDER WATER DRAIN
