Mercedes A0015420219 - РЕЛЕ

200 T 124.080 200-300 9/89-10/92, 200D-300D 9/89-7/93

42 BRAKES - 001 ANTI-LOCK BRAKING SYSTEM (FOR TYPES 124, 129,201,SEE STANDARD VERSION) IL.4

Поз.
Артикул
Описание
5
A1248201617
ELECTRIC CABLE FROM TAIL LAMP TO RELAY AND TO DISTRIBUTOR
8
A1248201517
ELECTRIC CABLE FROM DISTRIBUTOR TO BLINKER LAMP
14
A1235454940
BRACKET COUPLER
20
N007981004318
SHEET METAL SCREW ANTENNA CABLE TO REAR INSIDE PILLAR
32
A0015420219
RELAY , 123.003,028 105805 123.026 106004 123.030 032306 123.033 090757 123.053 023337 123.086 007202 123.093 009553 123.120 262872 123.102,103,125 255626 123.123 254722 123.105,132 240923 123.130 240457 123.183 016222 123.190 022642 123.200 040194 123.220 031448 123.223 040309 123.243 006912 123.280 001558 123.283 005502
38
A1248200721
BLINKER LAMP
41
N072601012190
BULB12 V
44
A0019946945
LOCK , A 448772 F 035728 FOR THE NEW PART NO.,SEE STANDARD VERSION,GROUP 68
47
A1247400219
RAIL , NO.9051I NO.5076I NO.8316I NO.8326I NO.8412I NO.6122I NO.3112I NO.7101I I
50
A1247420112
ANGLE LEFT
50
A1247420212
ANGLE RIGHT
53
N910002003100
RIVET
