Поз.
Артикул
Описание
10
INTAKE MANIFOLD
10
AC SUCTION PIPE , Replaced By: A4508300053, +001A4508320123, +001N000000002191
20
O-RING17,17 X 1,78
100
AC HOSE SUCTION SIDE , Replaced By: A4508320123, +001A4508300053, +001N000000002191
100
MOLDED HOSE
110
SEAL RING SUCTION LINE 13.7X2.5 MM, Replaced By: A0139974745
120
O-RING TO COMPRESSOR 13.94 X 2.62
130
HEXALOBULAR BOLT SPOILER FASTENING M8X35
200
PRESSURE LINE
200
AC PRESSURE PIPE , Replaced By: A4508320015, +001A4508320023, +001N000000002191
210
O-RING10,82 X 1,78
300
MOLDED HOSE
300
AC HOSE PRESSURE SIDE , Replaced By: A4508320023, +001A4508320015, +001N000000002191
310
SEALING RING HIGH PRESSURE LINE 9.5X2.5
320
O-RING10 X 2.62
330
HEXALOBULAR BOLT SPOILER FASTENING M8X35
400
AC FLUID PIPE
410
O-RING NEW VEHICLE 8-7.50 , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO., Replaced By: A0279979548
420
SEAL RING LOW PRESSURE LINE TO STEERING
500
NUT BRACKET TO BODY SHELL M6
510
NUT BRACKET TO BODY SHELL M6
520
BRACKET FRONT
525
RUBBER AC LINE CLIP
530
BRACKET REAR
540
AC LINE CLIP FRONT
545
PLASTIC SCREW TORX M6 X 1
700
MOUNTING SET FRESH-UP
720
EXPANSION VALVE
800
RIVET WELDING STUD REPAIR SOLUTION FOR RUPTURED WELDED PINS
