Поз.
Артикул
Описание
605
CABLE HARNESS
605
CABLE HARNESS MAIN CABLE HARNESS 24 V, 109015
605
CABLE HARNESS MAIN CABLE HARNESS
605
CABLE HARNESS MAIN CABLE HARNESS
605
CABLE HARNESS MAIN CABLE HARNESS 24 V
605
CABLE HARNESS MAIN CABLE HARNESS 24 V, 109016
615
ELECTRIC CABLE CONTROL UNIT EZL
633
CABLE SHOE
633
CABLE SHOE. CABLE LUGH2.11/12, A4-2.5 TO 0045424420 / 4520
635
GROMMET1.75 MM
637
PIN BUSHING HOUSING 5-POLE
639
SOCKET. PIN BUSHING LESS DETENT,BUT WITH CATCH FOR HOUSING 2,5 MM2
639
PIN BUSHING , Replaced By: A0075458226
641
CABLE SHOEA 6-2,5
643
GROMMET1.75 MM
643
GROMMET3.0 MM
647
PIN BUSHING HOUSING UNIPOLAR
649
PIN BUSHING WITH DETENT AND WITH CATCH FOR HOUSING 2.5 MM2
649
PIN BUSHING WITH DETENT AND WITH CATCH FOR HOUSING 2,5 MM2
651
PIN BUSHING HOUSING 3-POLE
653
PIN BUSHING OFFSET 4 MM2
655
PIN BUSHING HOUSING
657
PIN BUSHING WITH DETENT,LESS CATCH FOR HOUSING 6 MM2,5 097182
657
PIN BUSHING , Replaced By: A0075458226
657
SOCKET. PIN BUSHING LESS DETENT,BUT WITH CATCH FOR HOUSING 2,5 MM2
659
PIN BUSHING HOUSING UNIPOLAR
661
PIN BUSHING HOUSING BIPOLAR
663
PIN BUSHING WITH DETENT AND WITH CATCH FOR HOUSING 2,5 MM2
663
PIN BUSHING WITH DETENT AND WITH CATCH FOR HOUSING 2.5 MM2
669
GROMMET
671
BOOT HORN
673
PIN BUSHING LESS DETENT,BUT WITH CATCH FOR HOUSING 1-2.5 MM2
673
PIN BUSHING WITH DETENT,LESS CATCH FOR HOUSING 6 MM2,5 097182
673
PIN BUSHING LESS DETENT 1-2.5 MM2
675
BOOTTO 007 545 07 28
693
PIN BUSHING WITH DETENT,LESS CATCH FOR HOUSING 6 MM2,5 097182
695
PIN BUSHING HOUSING UNIPOLAR
697
CABLE SHOE GROUND TO STEERING COLUMN JACKET TUBE
697
CABLE SHOE. CABLE LUGH2.11/12, A4-6 TO 0045424420/4520
697
CABLE SHOE. CABLE LUGH2.11/12, A4-2.5 TO 0045424420 / 4520
697
CABLE SHOE CABLE HARNESS CONNECTION/SCREW-CONNECTION
697
CABLE SHOEA 6-6
697
CABLE SHOE CABLE ON GROUND POINT A 6X3,4
705
GROMMET HEADLAMP WIPER/WASHER
705
GROMMET , Replaced By: A0029971081
707
GROMMET HEADLAMP
709
GROMMET
711
GROMMET
749
PLUG HOUSING
751
PLUG PIN
753
PIN BUSHING HOUSING TELL-TALE LAMP ASD
755
ROUND PIN BUSHING LIGHT SWITCH 2,5 MM
775
COVERTO 010 545 10 28
777
PIN BUSHING HOUSING BIPOLAR
779
ROUND PIN BUSHING WITH DETENT AND WITH CATCH FOR HOUSING 2.5 MM2
847
PIN BUSHING HOUSING UNIPOLAR
849
PIN BUSHING WITH DETENT,LESS CATCH FOR HOUSING 6 MM2,5 097182
851
CABLE SHOEA 6-6
851
CABLE SHOEA 8-6
853
END-TYPE TERMINAL
859
SCREW , Replaced By: N304017006018
859
SCREW COVER PLATE TO COVER PLATE M 6 X 12
860
NUT SPRING-LOADED PUSH ROD
861
SPRING WASHER LICENSE PLATE TO BRACKET
862
SHEET METAL SCREW MODULE TO HOUSING
862
SHEET METAL SCREW , Replaced By: N000000000453
863
WASHER , Replaced By: N000125004319
863
WASHER BRACKET TO SUPPORT
999
SCREW TOP
999
EXPANSION PLUG TO LOCK TRAILER-PLUG-SOCKET OUTLET
999
SCREW
999
GROMMET HOSE LINE PROTECTION TO 000 546 16 30,71 30
999
PLUG
999
RELAY
999
CABLE CONNECTOR FRAME,REAR
999
PIN BUSHING HOUSING UNIPOLAR
999
PLUG REAR CABLE CONNECTOR,5 180266
999
PIN BUSHING HOUSING HEADLAMP,WIPER MOTOR,BLOWER SWITCH
999
PLUG. FLAT PLUG LESS DETENT,BUT WITH CATCH FOR HOUSING 4.0-6.0 MM2
999
RESISTOR AUTOMATIC HEATING BLOWER MOTOR
999
COVER AUTOMATIC CUT-OUT
999
ELECTRIC CABLE FROM SERIES RESISTOR TO PRE-GLOW TIME RELAY
999
CABLE HARNESS BLOWER CABLE
999
BRACKET SERIES RESISTOR
999
GROUND STRAP GROUND CABLE TO FRAME AND TO CAB
999
GASKET POSITION LAMP
999
WASHER , Replaced By: N000433005304
999
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
999
WASHER BOOT TO CAB FLOOR
999
NUT , Replaced By: N304032005005
999
SHEET METAL SCREW BRACKET TO ELECTRICAL APPARATUS COMPARTMENT 4,8X19
999
SHEET METAL SCREW , Replaced By: N007981004252
999
SCREW PUMP TO BRACKET
999
NUT , Replaced By: N304032005005
999
NUT IN CASE OF SUBSEQUENT INSTALLATION
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
