Mercedes A0115451628 - Штифт

G 270 CDI 463.322 FROM CHASSIS 144226

54 ELECTRICAL EQUIPMENT AND INSTRUMENTS - 420 MAIN CABLE HARNESS IL. 3

Поз.
Артикул
Описание
30
A0125458228
PLUG HOUSINGADS-ASD
40
A0115451628
PLUG PIN
50
A0295455528
PIN BUSHING HOUSING WARNING DEVICE
60
A0005404605
REP.SET CONTACT0.75 MM2 MQS, CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED. SEE WIS FOR REPAIR INSTRUCTIONS.SOLDER CONNECTOR SLEEVES:TOTAL WIRE CROSS-SECTION: A 001 546 99 41GREEN0.7 -2.4 MM2 A 002 546 00 41RED2.0 -4.0 MM2 A 002 546 01 41BLUE 3.5 -8.0 MM2 A 002 546 11 41YELLOW 7.5 - 12.0 MM2 BUTT JOINT: A 002 546 13 41 0.5 MM2 A 002 546 14 41 0.8 MM2 A 002 546 15 41 1.3 MM2 A 002 546 16 41 2.0 MM2
60
A0085455526
CONTACT BUSHINGR 27, 0.75 MM2
70
A4145450026
PLUG HOUSING ILLUMINATED DOOR SILL MOLDING CONTROL UNIT 8-PIN AMP SERIE 040,N99/9,N99/10
80
A0165457826
PIN BUSHING0.35-0.5 MM2 AMP SERIE 040
200
A4635400106
WIRING HARNESS
210
A0305455928
PLUG INFRARED REMOTE CONTROL RECEIVER, FRONT DOOR, FROM MODEL YEAR 1999
220
A0325453928
PLUG PINX 209, 0.75 MM2
