Поз.
Артикул
Описание
10
TIMING CASE
10
TIMING CASE
10
TIMING CASE
10
TIMING CASE
10
TIMING CASE , Replaced By: A4710153402
10
TIMING CASE
10
TIMING CASE
10
TIMING CASE
10
TIMING CASE , Replaced By: A4710158202
10
TIMING CASE , Replaced By: A4710153502
12
CLOSING COVER TIMING CASE TO A 471 010 04 33
14
GASKET
16
SCREW BRACKET TO SIDE MEMBER M10X35
20
STUD STARTING MOTOR MOUNTING M 12X35
30
STUD BOLT STARTING MOTOR MOUNTING
30
STUD STARTING MOTOR MOUNTING, Replaced By: A0029903314
40
NUT. HEXAGON NUT STRAP TO CONSOLE M12X1.5
50
COVER TIMING CASE
60
HEXAGON HEAD BOLT. SCREW CLUTCH TO FLYWHEEL M8X16 MM
70
CLOSING COVER PLUG, TRANSMISSION ACCESS OPENING
80
COVER PLUG, OPENING FOR GEAR DRIVEADJUSTMENT
90
GASKET PLUG, OPENING FOR GEAR DRIVEADJUSTMENT
100
HEXAGON HEAD BOLT CLAMP AT SUPPORTING RAIL M 8X30
110
RADIAL SHAFT SEALING RING , Replaced By: A0159974946
110
RADIAL SHAFT SEALING RING
120
GASKET
130
HEXAGON HEAD BOLT TIMING CASE AT CRANKCASE, TOP M14X1.5X180MM - 10.9
140
HEXAGON HEAD BOLT SHIFT LEVER TO CAB FLOOR M 8X45
145
HEXAGON HEAD BOLT. SCREW BRACKET TO AIR INTAKE PIPE M 10X45
150
HEXAGON HEAD BOLT. SCREW SHIFTING TUBE TO SHIFT LEVER M 10X90
155
HEXAGON HEAD BOLT MOUNTING, TORSION BAR, ON SIDE MEMBER M14X1.5X90
170
HEXAGON HEAD BOLT MOUNTING, TORSION BAR, ON SIDE MEMBER M14X1.5X90
172
CLOSING COVER TIMING CASE TO A 471 010 04 33
174
GASKET
176
SCREW BRACKET TO SIDE MEMBER M10X35
