Поз.
Артикул
Описание
5
ALTERNATOR28V 35A, WITH TERMIANL "W"
5
ALTERNATOR28V/55A, BOSCH
5
ALTERNATOR , Replaced By: A3761507750
5
ALTERNATOR WITH REGULATOR INCORPORATED AND PULLEY 28V/55A "BOSCH"
35
SCREW , Replaced By: A0019906420
35
SCREWTO 344 150 73 50
35
SCREWTO 345 150 76 50
35
SCREW
35
SCREW , MODEL 343.919.000 FROM ENGINE 154150,MODEL 344.919.000 FROM ENGINE 822957
35
SCREW , Replaced By: A0009909621
35
SCREW
50
LOCK WASHERTO 344 150 73 50
70
BALL BEARING DRIVE END BEARING, APPLICABLE TO ALTERNATOR HAVING BOSCH NO.0 120 469 686
70
GROOVED BALL BEARING , Replaced By: N000625436303
70
BALL BEARINGTO 007 154 27 02, 009 154 07 02
70
BALL BEARING , Replaced By: A0079816625
105
BALL BEARINGTO 007 154 27 02, 009 154 07 02
105
BALL BEARINGTO 005 154 34 02
105
BALL BEARING , Replaced By: A0089811225
110
SEAL RINGTO 005 154 34 02
195
COIL , Replaced By: A0001546725
195
COIL , Replaced By: A0001546925
195
COILTO 366 150 07 50, APPLICABLE TO ALTERNATOR HAVING BOSCH NO.0 120 469 982
195
COILTO 344 150 74 50,78 50
195
COIL EXCITER
205
RECTIFIERTO 005 154 45 02,006 154 86 02
205
RECTIFIER
205
RECTIFIER
205
RECTIFIER , Replaced By: A0011541116
205
RECTIFIER , Replaced By: A0001545116
205
RECTIFIER , Replaced By: A0011541616
205
RECTIFIER , Replaced By: A0011542116
205
RECTIFIER , Replaced By: A0011542116
215
SCREW
215
SCREW T-FITTING TO BRACKET M4X25
215
SCREW
220
LOCK WASHERTO 344 150 74 50,78 50
230
CONDENSER , Replaced By: A0011566701
230
CONDENSER
240
SCREW
240
SCREW CONDENSER TO ALTERNATOR
245
SPRING WASHER HEATER PLUG CABLE HARNESS
245
LOCK WASHERTO 376 150 74 50
265
REGULATOR AND CUT-OUT , Replaced By: A0001541705
265
REGULATOR AND CUT-OUT
265
REGULATOR AND CUT-OUTTO 344 150 73 50
265
REGULATORTO 007 154 27 02
275
CARBON BRUSH SET
275
CARBON BRUSH SETTO 366 150 07 50, 376 150 83 50
275
CARBON BRUSH SET , APPLICABLE TO ALTERNATOR HAVING BOSCH NO.0 120 469 982
275
CARBON BRUSH SETTO 007 154 27 02
275
CARBON BRUSH SET , Replaced By: A0001549814
275
CARBON BRUSH SET , Replaced By: A0001548114
285
SPRING
285
SPRING
290
SCREW
290
SCREWTO 344 150 73 50
290
SCREW REGULATOR MOUNTING TO 009 154 07 02
295
LOCK WASHERTO 344 150 74 50,78 50
305
INSULATING PART PARTS KIT B+, MODEL 343.919.000 FROM ENGINE 154150,MODEL 344.919.000 FROM ENGINE 822957
310
INSULATING PART PARTS KIT
315
INSULATING PART , OM 352 FROM ENGINE 823237,OM 352 A FROM ENGINE 822957
335
REPAIR KIT (PARTS KT),ROTOR TO 007 154 27 02,009 154 07 02
335
REPAIR KIT
335
REPAIR KIT ROTOR TO 007 154 28 02
345
TERMINAL TERMINALS: B+, B-, D+, W
350
FANTO 005 154 34 02,007 154 27 02/07 02,208848/91
350
FAN WITH PULLEY
350
FANTO 344 150 74 50
350
FAN WITH PULLEY
999
BALL BEARING TIGHTENER PULLEY
999
BALL BEARING
999
V-BELT LOW TENSIBILITY 12.5X1718 MM, FROM IDENT NO. 004703 ALSO INSTALLED ON 004316,004586,004634,004640,004650,004662,004673
999
V-BELT12.5X1675
999
ALTERNATORN1 28V 10/55A, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
CLAMPING PIECE TIGHTENER PULLEY TO LEVER
999
HUBTO 343 150 73 50,376 150 87 50,82 50
999
PULLEYTO 343 150 73 50, 376 150 83 50
999
ALTERNATOR
999
ALTERNATOR
999
NUT TIGHTENER PULLEY TO LEVER
999
SUPPORT TIGHTENER PULLEY
999
TIGHTENER PULLEY
999
CLAMPING PIECE
999
CAP
999
BRACKET BELT TENSION READJUSTMENT
999
SPACER TUBE BRACKET AND FILLER NECK ON WATER PUMP
999
CLAMPING BOLT FOR V-BELT TENSIONING
999
SUPPORT
999
BRACKET CLAMPING BOLT
999
CLAMPING BOLT
999
CLAMPING BOLT (CLAMPING BOLT)
999
ALTERNATOR
999
WASHER SUPPORT TO FRAME,D 127794
999
LOCK RING
999
SCREW PIPE ELBOW TO CHARGING AIR INTERCOOLER M 10X35,5 708090
999
SCREW FENDER TO BRACKET, NOT USED
999
SCREW
999
SCREW TORSION BAR TO SHACKLE,5 903514
