Поз.
Артикул
Описание
5
BRACKET BRACKET TO WATER RADIATOR, ON VEHICLES HAVING MERCEDES-BENZ BODY FROM CHASSIS 035942 ON VEHICLES HAVING NO MERCEDES-BENZ BODY FROM CHASSIS 035887
8
CLAMP , Replaced By: A1109950401
11
CLAMP ,K 147121, Replaced By: N000000000319
11
CLAMP SENSOR CABLE TO BRACKET
11
CLAMP LINE TO SIDE MEMBER
11
CLAMP LINE MOUNTING
14
CLAMP LINE MOUNTING
14
CLAMP LINES TO BRACKET
14
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
17
SCREW CAB FLOOR COVERING M 6X25
17
SCREW , Replaced By: N304017006020
17
SCREW , Replaced By: N304017006016
20
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
20
SCREW , Replaced By: N304017008016
23
SHEET METAL SCREW OIL LINE MOUNTING
26
WASHER , Replaced By: N009021006208
29
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
32
NUT , Replaced By: N910113006001
32
NUT , Replaced By: N913004006001
35
NUT BRACKET TO SIDE MEMBER
38
LOOM TIE365 MM
38
LOOM TIE LINE MOUNTING
38
LOOM TIE
38
LOOM TIE , Replaced By: A0019978390
41
FITTING FROM 3/2-WAY VALVE TO PRESSURE CONTROL VALVE
44
NUT LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
47
WASHER
50
BRAKE HOSE FROM TEST CONNECTION TO T-FITTING
50
BRAKE HOSE FROM BRAKE HOSE TO CONNECTOR,FRONT AXLE CIRCUIT
53
FITTING (PARTS KIT),LINE RUPTURE
55
BRAKE HOSE FROM CONNECTOR I TO CONNECTOR II
56
BRAKE HOSE SPRING-LOAD ACCUMULATOR CYLINDER TWOWAY VALVE,LEFT
59
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
62
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
65
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
68
T-FITTING BRANCH-OFF TO REAR DIAPHRAGM CYLINDERS
71
FITTING AT VALVE
74
FITTING DELIVERY LINE TO PUMP
75
ELBOW FITTING TRAILER CONTROL VALVE,CONNECTION: 1.1
77
SEALING RING. SEAL RING DELIVERY LINE TO STEERING
80
THRUST RING COMPRESSED AIR LINE TO AIR RESERVOIR AND TO T-FITTING
83
SEAL RING TO 18-MM-DIA. COMPRESSED AIR LINES
86
BRAKE HOSE FROM AIR COMPRESSOR TO PRESSURE REGULATOR
86
BRAKE HOSE COMPRESSED AIR LINE TO COMPRESSED AIR LINE
89
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTION: "2"
92
NUT BRACKET TO SIDE MEMBER
95
WASHER COVERING TO BEARING BRACKET
98
FITTING RELAY VALVE,CONNECTION: "10",950459
101
UNION NUT LINE CONNECTION, Replaced By: N000000006239
104
SEAL CONE LINE CONNECTION
104
GLAND , Replaced By: A0019901967
107
TEST CONNECTION
110
FITTING FROM 3/2-WAY VALVE TO PRESSURE CONTROL VALVE
113
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
113
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
113
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
113
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
113
TEST CONNECTION
